ATT System 25 Installation And Maintenance Manual

APPENDIX F: Administration Error Messages
ERROR MESSAGE
AND DESCRIPTlONPOSSIBLE SOLUTION
1017:inappropriate request
Cap already installed
system already has Direct
CAPACTION =
1 (Cap)
Go to MENU 8 (Searches)
ACTION = 1 DATA = 18
ACTION = 2 DATA = 309 or 310
ACTION = 3 DATA = 0
1018:inappropriate requestMust remove secondary CAP before
must remove secondary
attempting to remove the first CAP.
CAP first
1019:incorrect action number
Check if the ACTION value taken is
does not exist or used
legal....

APPENDIX F: Administration Error Messages
ERROR MESSAGE
AND DESCRIPTIONPOSSIBLE SOLUTlON
1031:
at installed maxAt system maximum of 12 touch-
-12 Touch-Tonetone receivers.
Receivers
1032:
at installed maxAt system maximum of 8 external
-8 external alertalerts
1033:at installed maxAt system maximum of 3 paging
-3 paging zoneszones.
1034:at installed maxAt system maximum of 2 Direct
2 announcement machineNight Service Delay Announcements
or limit of 1 delay announcement for
DGC groups.
1035:
at installed...

APPENDIX F: Administration Error Messages
ERROR MESSAGE
AND DESCRIPTION
POSSIBLE SOLUTION
1044:
inappropriate request
Neither primary nor secondary CAP
primary or secondary CAP
universal port number agrees with the
unavailableone stored by admin. on the stack.
1045:
at installed max
At system maximum of 104 data
-104 data port
ports.
1046:incorrect button
Duplicate button function code found.
function code
button facility already
exists
1047:incorrect button number
Button number out of range for voice...

APPENDIX F: Administration Error Messages
ERROR MESSAGE
AND DESCRIPTIONPOSSIBLE SOLUTION
1056:inappropriate requestTrying to administer something other
must be virtual facilitythan a Virtual digit. [0-9, *, #]
Must be a Virtual Facility.
1057:at installed maxGroup or button maximum reached.
System btn or stationStation is sender in group.
group max reached
1058:incorrect entryCan only enter numerical values for
illegal character withintrunk number. Unexpected ASCII
datacharacter received....

APPENDIX F: Administration Error Messages
ERROR MESSAGE
AND DESCRIPTION
1069:incorrect facility type
incompatible with board
type
1070:facility type out
of range
must be 3-4 digits
POSSIBLE SOLUTION
Board and features do not mix.
Check slot location for correct
board or not compatible with the
already entered types on the board.
Must be 3 or 4 digits.
1071:
inappropriate request
name does not existName does not exists. Go to
MENU 8 (Search)
ACTION = 1 DATA = 40
ACTION = 2 DATA = PDC
Hit c to continue to...

APPENDIX F: Administration Error Messages
ERROR MESSAGE
AND DESCRIPTIONPOSSIBLE SOLUTION
1083:inappropriate requestRecheck translations to see if TT
TT generator not installedgenerator was installed.
1084:inappropriate requestTrying to administer a third CAP
system already has twowhen you are only allowed two.
CAPS
1085:incorrect entryData parity setting must be between
must be 0-3 if parity, else0-3. Delay break for STARLAN is
0-10-1.
1086:inappropriate request
Cannot assign a DID trunk port an
DID...

APPENDIX F: Administration Error Messages
ERROR MESSAGE
AND DESCRIPTIONPOSSIBLE SOLUTION
1094:
inappropriate requestDisplay attendant position
only DISPLAY of SLC-DTAC/SLAC. See:
CAP status allowedMENU = 1 (Port)
ACTION = 60
for more information.
1095:
action numberCheck MENU 4 (System
out of sequenceAdministration) for administering
must enter 90 &/or 91correct sequence.
first
1096:
entry out of rangeCall type priority must be between
data must be 1-71-7. Check MENU 4 Action item 92.
1097:
entry out of...

APPENDIX F: Administration Error Messages
ERROR MESSAGE
AND DESCRIPTIONPOSSIBLE SOLUTION
2003:incorrect button numberCheck button range for station type.
out of range for ATL set
2004:inappropriate requestCannot administer button features
EMT can’t have button
on an EMT station or not allowed
for particular type of service.
2007:incorrect facility typeEMT station is required.
must be EMT
2009:inappropriate requestMust enter PDC before you
must enter PDC first
continue.
2011:incorrect entryData value must...

APPENDIX F: Administration Error Messages
ERROR MESSAGE
AND DESCRIPTIONPOSSIBLE SOLUTION
2026:incorrect entryCheck to see if trunk is
trunk does not existadministered. No such trunk ID.
2027:inappropriate requestCannot assign night service to a
not optioned for night
DID trunk. Trunk not optioned for
servicenight service.
2029:
inappropriate requestStation already assigned to this
trunk already assignedtrunk.
station
2030:
out of spaceThe maximum allowable night
trunk station maxservice trunks per...

APPENDIX F: Administration Error Messages
ERROR MESSAGE
AND DESCRIPTIONPOSSIBLE SOLUTION
2039:inappropriate request
Cannot assign buttons that are
buttons fixed- can’talready fixed on the CAP.
assign
2040:incorrect PDC
Has to be an ATL station to assign
must be station for prime
prime line preference.
line pref
2041:inappropriate request
Has to be an ATL station to assign
must be ATL set for
prime line preference.
prime line pref
2043:out of spaceSystem maximum reached for ATL
no more button sets...
