Page 11
![Page 11
fi-6130 / fi-6230 Image Scanner Operators Guide
TROUBLESHOOTING
CONTENTS MAP
TOP
Safety Precautions (3)
1 2 3 4
CAUTION
Do not install the scanner on unstable surfaces.
Make sure that the scanner is installed on a flat, level surface and tha\
t none of its parts extend
beyond the surface top, such as a desk or table. Do not install the scan\
ner on unstable surfaces.
Install the scanner on a level surface that is free of vibration to prev\
ent it from falling.
Install...](http://img.usermanuals.tech/thumb/26/59946/w300_fujitsu-fi6130-operators-manual-1488462901_d-10.png "Page 11
fi-6130 / fi-6230 Image Scanner Operators Guide
TROUBLESHOOTING
CONTENTS MAP
TOP
Safety Precautions (3)
1 2 3 4
CAUTION
Do not install the scanner on unstable surfaces.
Make sure that the scanner is installed on a flat, level surface and tha\
t none of its parts extend
beyond the surface top, such as a desk or table. Do not install the scan\
ner on unstable surfaces.
Install the scanner on a level surface that is free of vibration to prev\
ent it from falling.
Install...")
fi-6130 / fi-6230 Image Scanner Operators Guide TROUBLESHOOTING CONTENTS MAP TOP Safety Precautions (3) 1 2 3 4 CAUTION Do not install the scanner on unstable surfaces. Make sure that the scanner is installed on a flat, level surface and tha\ t none of its parts extend beyond the surface top, such as a desk or table. Do not install the scan\ ner on unstable surfaces. Install the scanner on a level surface that is free of vibration to prev\ ent it from falling. Install...
Page 12
![Page 12
fi-6130 / fi-6230 Image Scanner Operators Guide
TROUBLESHOOTING
CONTENTS MAP
TOP
Safety Precautions (4)
1 2 3 4
CAUTION
Protect the scanner from static electricity.
Install the scanner away from strong magnetic fields and other sources o\
f electronic noise. Also,
protect the scanner against any static electricity, which can cause the \
scanner to malfunction.
Avoid any contact when scanner is in use.
Avoid getting a sleeve, necktie, or hair caught up in any scanner...](http://img.usermanuals.tech/thumb/26/59946/w300_fujitsu-fi6130-operators-manual-1488462901_d-11.png "Page 12
fi-6130 / fi-6230 Image Scanner Operators Guide
TROUBLESHOOTING
CONTENTS MAP
TOP
Safety Precautions (4)
1 2 3 4
CAUTION
Protect the scanner from static electricity.
Install the scanner away from strong magnetic fields and other sources o\
f electronic noise. Also,
protect the scanner against any static electricity, which can cause the \
scanner to malfunction.
Avoid any contact when scanner is in use.
Avoid getting a sleeve, necktie, or hair caught up in any scanner...")
fi-6130 / fi-6230 Image Scanner Operators Guide TROUBLESHOOTING CONTENTS MAP TOP Safety Precautions (4) 1 2 3 4 CAUTION Protect the scanner from static electricity. Install the scanner away from strong magnetic fields and other sources o\ f electronic noise. Also, protect the scanner against any static electricity, which can cause the \ scanner to malfunction. Avoid any contact when scanner is in use. Avoid getting a sleeve, necktie, or hair caught up in any scanner...
Page 13
fi-6130 / fi-6230 Image Scanner Operators Guide TROUBLESHOOTING CONTENTS MAP TOP Chapter 1 NAMES AND FUNCTIONS OF PARTS This chapter describes the scanner parts and their functions. All Rights Reserved. Copyright 2007 © PFU LIMITED
Page 14
![Page 14
fi-6130 / fi-6230 Image Scanner Operators Guide
TROUBLESHOOTING
CONTENTS MAP
TOP
1.1 Checking the Contents of the Scanner Package
When you open the scanner package, please handle the main unit and its a\
ttachments carefully.
Make sure it contains all the parts listed in the package contents list \
that is included in the package box.
If any parts are missing or defective, contact the dealer where you purc\
hased the scanner or an authorized FUJITSU scanner
service provider....](http://img.usermanuals.tech/thumb/26/59946/w300_fujitsu-fi6130-operators-manual-1488462901_d-13.png "Page 14
fi-6130 / fi-6230 Image Scanner Operators Guide
TROUBLESHOOTING
CONTENTS MAP
TOP
1.1 Checking the Contents of the Scanner Package
When you open the scanner package, please handle the main unit and its a\
ttachments carefully.
Make sure it contains all the parts listed in the package contents list \
that is included in the package box.
If any parts are missing or defective, contact the dealer where you purc\
hased the scanner or an authorized FUJITSU scanner
service provider....")
fi-6130 / fi-6230 Image Scanner Operators Guide TROUBLESHOOTING CONTENTS MAP TOP 1.1 Checking the Contents of the Scanner Package When you open the scanner package, please handle the main unit and its a\ ttachments carefully. Make sure it contains all the parts listed in the package contents list \ that is included in the package box. If any parts are missing or defective, contact the dealer where you purc\ hased the scanner or an authorized FUJITSU scanner service provider....
Page 15
fi-6130 / fi-6230 Image Scanner Operators Guide TROUBLESHOOTING CONTENTS MAP TOP 1.2 Names and Functions of Parts This section describes the scanner parts and their functions. Front No. Name Function 1 ADF (Automatic Document Feeder) Transports the document to the reading position automatically. 2 ADF paper chute Holds in place the document pages / sheets that are fed into the ADF. 3 Paper chute extension 1 4 Paper chute extension 2 5 Side Guide Adjusted to the width of...
Page 16
![Page 16
No. Name Function
1 Document bed Place documents on the glass when scanning through the flatbed.
2 Document holding
pad Holds documents down on the document bed.
3 Document cover Holds the documents loaded at the reading position when closed.
HINT
The document cover with a black document holding pad is optionally avail\
able.
This type is convenient for scanning documents in black background when \
loading them from
the flat bed.
l Name: Black Document Pad (fi-624BK)
l Parts No.:...](http://img.usermanuals.tech/thumb/26/59946/w300_fujitsu-fi6130-operators-manual-1488462901_d-15.png "Page 16
No. Name Function
1 Document bed Place documents on the glass when scanning through the flatbed.
2 Document holding
pad Holds documents down on the document bed.
3 Document cover Holds the documents loaded at the reading position when closed.
HINT
The document cover with a black document holding pad is optionally avail\
able.
This type is convenient for scanning documents in black background when \
loading them from
the flat bed.
l Name: Black Document Pad (fi-624BK)
l Parts No.:...")
No. Name Function 1 Document bed Place documents on the glass when scanning through the flatbed. 2 Document holding pad Holds documents down on the document bed. 3 Document cover Holds the documents loaded at the reading position when closed. HINT The document cover with a black document holding pad is optionally avail\ able. This type is convenient for scanning documents in black background when \ loading them from the flat bed. l Name: Black Document Pad (fi-624BK) l Parts No.:...
Page 17
![Page 17
Parts that can be removed from the scanner are displayed below.
No. Name
1 ADF paper chute
2 Pick roller
3 Brake roller
4 Document cover [fi-6230 only]
All Rights Reserved. Copyright 2007 © PFU LIMITED](http://img.usermanuals.tech/thumb/26/59946/w300_fujitsu-fi6130-operators-manual-1488462901_d-16.png "Page 17
Parts that can be removed from the scanner are displayed below.
No. Name
1 ADF paper chute
2 Pick roller
3 Brake roller
4 Document cover [fi-6230 only]
All Rights Reserved. Copyright 2007 © PFU LIMITED")
Parts that can be removed from the scanner are displayed below. No. Name 1 ADF paper chute 2 Pick roller 3 Brake roller 4 Document cover [fi-6230 only] All Rights Reserved. Copyright 2007 © PFU LIMITED
Page 18
![Page 18
fi-6130 / fi-6230 Image Scanner Operators Guide
TROUBLESHOOTING
CONTENTS MAP
TOP
1.3 Functions of the Operator Panel
The operator panel is located on the right side of the scanner. This pan\
el is comprised of a Function Number display, four
buttons, and a LED.
No. Name Function
1 Check LED Lights when an error occurs.
2 Function Number Display Indicates the function number and error status.
3 Function Button Changes the Function activated by the Send to button (*).
4 Send...](http://img.usermanuals.tech/thumb/26/59946/w300_fujitsu-fi6130-operators-manual-1488462901_d-17.png "Page 18
fi-6130 / fi-6230 Image Scanner Operators Guide
TROUBLESHOOTING
CONTENTS MAP
TOP
1.3 Functions of the Operator Panel
The operator panel is located on the right side of the scanner. This pan\
el is comprised of a Function Number display, four
buttons, and a LED.
No. Name Function
1 Check LED Lights when an error occurs.
2 Function Number Display Indicates the function number and error status.
3 Function Button Changes the Function activated by the Send to button (*).
4 Send...")
fi-6130 / fi-6230 Image Scanner Operators Guide TROUBLESHOOTING CONTENTS MAP TOP 1.3 Functions of the Operator Panel The operator panel is located on the right side of the scanner. This pan\ el is comprised of a Function Number display, four buttons, and a LED. No. Name Function 1 Check LED Lights when an error occurs. 2 Function Number Display Indicates the function number and error status. 3 Function Button Changes the Function activated by the Send to button (*). 4 Send...
Page 19
![Page 19
fi-6130 / fi-6230 Image Scanner Operators Guide
TROUBLESHOOTING
CONTENTS MAP
TOP
Chapter 2 BASIC SCANNER OPERATIONS
This chapter describes basic scanner operations.
In this chapter Windows XP screenshots are illustrated. The screens and \
operations may differ slightly if the OS that you are
using is other than Windows XP.
Also, when the FUJITSU TWAIN32 or FUJITSU ISIS scanner driver is updated\
the screens and operations noted in this chapter
will differ slightly. In such case,...](http://img.usermanuals.tech/thumb/26/59946/w300_fujitsu-fi6130-operators-manual-1488462901_d-18.png "Page 19
fi-6130 / fi-6230 Image Scanner Operators Guide
TROUBLESHOOTING
CONTENTS MAP
TOP
Chapter 2 BASIC SCANNER OPERATIONS
This chapter describes basic scanner operations.
In this chapter Windows XP screenshots are illustrated. The screens and \
operations may differ slightly if the OS that you are
using is other than Windows XP.
Also, when the FUJITSU TWAIN32 or FUJITSU ISIS scanner driver is updated\
the screens and operations noted in this chapter
will differ slightly. In such case,...")
fi-6130 / fi-6230 Image Scanner Operators Guide TROUBLESHOOTING CONTENTS MAP TOP Chapter 2 BASIC SCANNER OPERATIONS This chapter describes basic scanner operations. In this chapter Windows XP screenshots are illustrated. The screens and \ operations may differ slightly if the OS that you are using is other than Windows XP. Also, when the FUJITSU TWAIN32 or FUJITSU ISIS scanner driver is updated\ the screens and operations noted in this chapter will differ slightly. In such case,...
Page 20
![Page 20
fi-6130 / fi-6230 Image Scanner Operators Guide
TROUBLESHOOTING
CONTENTS MAP
TOP
2.1 Turning the Scanner ON
This section describes how to turn the scanner ON.
The following shows the procedure for turning the scanner ON.
1. Press the Power button on the Operator Panel.
The scanner is turned ON, and the Power LED on the Operator Panel lights\
in green.
Also, while the scanner is being initialized, the indication of the Func\
tion Number Display changes as follows:
8 -> P...](http://img.usermanuals.tech/thumb/26/59946/w300_fujitsu-fi6130-operators-manual-1488462901_d-19.png "Page 20
fi-6130 / fi-6230 Image Scanner Operators Guide
TROUBLESHOOTING
CONTENTS MAP
TOP
2.1 Turning the Scanner ON
This section describes how to turn the scanner ON.
The following shows the procedure for turning the scanner ON.
1. Press the Power button on the Operator Panel.
The scanner is turned ON, and the Power LED on the Operator Panel lights\
in green.
Also, while the scanner is being initialized, the indication of the Func\
tion Number Display changes as follows:
8 -> P...")
fi-6130 / fi-6230 Image Scanner Operators Guide TROUBLESHOOTING CONTENTS MAP TOP 2.1 Turning the Scanner ON This section describes how to turn the scanner ON. The following shows the procedure for turning the scanner ON. 1. Press the Power button on the Operator Panel. The scanner is turned ON, and the Power LED on the Operator Panel lights\ in green. Also, while the scanner is being initialized, the indication of the Func\ tion Number Display changes as follows: 8 -> P...
