2) Rotate the Pick roller lever in the direction of the arrow.
  0 Lever

3) Close the sheet guide. Make sure that both sides of the side guide a\
re firmly locked.

8.  Close the ADF. Press down on the center of the ADF to return it to its o\
riginal position until the ADF open leverlocks.


9.  Attach the ADF paper chute to the scanner.

  With the movie below, review the procedure to replace the Pick roller.



10.  Reset the Pick roller counter.
 For how to reset the Pick roller counter, see Section 5.2 How to Check and Reset the Consumables Counters.


All Rights Reserved. Copyright 2007 © PFU LIMITED

fi-6130 / fi-6230 Image Scanner Operators Guide



TROUBLESHOOTING
CONTENTS MAP
TOP

 Chapter 6 TROUBLESHOOTING



This chapter describes how to remedy document jams, other troubles, item\
s to check before contacting the agent where you
bought the scanner, and how to check device labels.

   ATTENTION
For information about troubles that are not described here, and the deta\
ils of the errors, refer to
the FUJITSU TWAIN32 Scanner Driver Help.


All Rights Reserved. Copyright 2007 ©...

fi-6130 / fi-6230 Image Scanner Operators Guide



TROUBLESHOOTING
CONTENTS MAP
TOP

 6.1 Removing Jammed Documents


If a document jam occurred, follow the procedure below to remove the jam\
med documents.
   ATTENTION
l     Take care not to get injured when removing jammed documents.
l     Be careful not to get neckties, necklaces, etc. entangled in the scanner\
 when
removing the jammed documents.
l     The surface of the glass and guides may become hot during operation. Tak\
e care not...

 Press center of ADF


 ATTENTION
l     Make sure that the ADF is completely closed. When it is not completely c\
losed,
feeding errors may occur.
l     When the scanning is completed or canceled, the documents might remain i\
nside the
ADF even though any error message is not displayed.

Follow the procedure below to remove the documetns remaining in the ADF.\

1.  Remove all documents from the ADF paper chute.
2.  Open the ADF by pulling the ADF open lever toward you.
3.  Remove the remaining...

fi-6130 / fi-6230 Image Scanner Operators Guide



TROUBLESHOOTING
CONTENTS MAP
TOP

 6.2 Error Indications on the Operator Panel



When any error occurs, the operator panel indicates [J] or [U] and a num\
ber alternately for temporary errors, or [E], [F], [C],
[H], [A], or [L] and a number alternately for device alarms (permanent \
error). Temporary errors can be solved by the operator,
but the device alarm require recovery works by support engineers.
If you want to clear the error...

IndicationMeaning Remedy
J1 Paper jam 1.  Remove the halted or jammed document remaining inside.
For how to remove such documents, see Section
6.1
Removing Jammed Documents.
2.  Confirm that the documents meet the paper conditions for
scanning from the ADF. For details see Chapter
7 ADF AND
SPECIFICATIONS.
J2 Multifeed error Pressing the [Send to] button on the Operator Panel ejects the
mutifed document.

l     Cover Open, Print, and Other Errors
 [U] and a number are displayed alternately....


IndicationMeaning Remedy
F4 Background switching
mechanism error  When you encounter this alarm on the display, turn the scanner off
and on. If the alarm is still displayed on the Function Number
Display, record the indicated error code, and contact the store
where you purchased the scanner or an authorized FUJITSU
scanner service provider.

l     Chips
 [C] and a number are displayed alternately.

Indication Meaning Remedy
C0 LSI error  When you encounter this alarm on the display, turn the...


IndicationMeaning Remedy
L6 Ultrasonic sensor error  When a device alarm is indicated, turn the scanner off and on.
If the alarm is still displayed on the Function Number Display, record
the indicated error code, and contact the store where you purchased
the scanner or an authorized FUJITSU scanner service provider.


All Rights Reserved. Copyright 2007 © PFU LIMITED

fi-6130 / fi-6230 Image Scanner Operators Guide



TROUBLESHOOTING
CONTENTS MAP
TOP

 6.3 Remedying Typical Troubles



This section describes troubles that may occur during scanning and how t\
o remedy those troubles.
Before you ask for repair, check the following flowcharts. If the remedi\
es in these flowcharts do not solve the problem, check the
items in Section
6.4 Items to Check Before Contacting the Dealer Where You Bought the Sca\
nner and then contact the dealer
where you...
