Diagnostic information2-155
7510
Go Back Previous
Next
11Check the transfer belt drive motor assembly drive gear for
damage.
1. Remove the transfer belt unit assembly. Go to
“Transfer belt drive motor assembly removal” on
page 4-93.
2. Inspect the transfer belt drive motor assembly drive gear
(D) for damage.
Is the transfer belt drive motor assembly drive gear
damaged?Replace the
transfer belt drive
motor assembly.Contact the next
level of support.
12Check the transfer belt steering motor for...

2-156Service Manual 7510
Go Back Previous
Next
904.02 Sensor (transfer belt edge) failure
Step Check Yes No
1Reset the transfer belt HP failure lock out condition.
1. Enter the Diagnostics Menu.
2. Touch Trans belt fail HP.
3. Touch Trans belt fail HP.
Does the transfer belt appear damaged or torn in half?Go to step 2. Go to step 3.
2Check the transfer belt unit assembly for proper installation.
Is the above component properly installed?Go to step 2. Re-install the
transfer belt unit
assembly.
3Check...

Diagnostic information2-157
7510
Go Back Previous
Next
3Are the PC cartridge units correctly installed?
Refer to the following images. Note that the far left PC
cartridge unit is tilted in the first image.
Incorrect:
Correct:Go to the next
step.Remove and
reinstall the PC
cartridge units
correctly. See “PC
cartridge unit
removal” on
page 4-54.
4Do the PC units easily slide in and out of the machine? Go to the next
step.Replace any
damaged PC units
or any damaged
erase lamp
assembly. See
“PC...

2-158Service Manual 7510
Go Back Previous
Next
5Check that the transfer belt steering mechanism lock
packaging was fully removed. If not removed before the
transfer belt lever is lowered, the transfer belt steering
mechanism lock might break and remain inside the machine
in the area, as showing in the following image (A).
The following images show the transfer belt steering
mechanism lock.
Are there any remnants from the packaging?Remove any
packaging
remnants.Go to the next
step.
6Check the...

Diagnostic information2-159
7510
Go Back Previous
Next
904.03 Sensor (2nd transfer roll retract HP) late error
Step Check Yes No
1Perform a POR.
Does the error occur when the power is turned off/on?Go to step 2. Perform several
print tests.
If the problem
remains, go to
step 2.
2Check to ensure that the transfer belt lift mechanism is
functioning properly. See “Transfer belt lift mechanism
adjustment” on page 4-277.
Does the error remain?Go to the next
step.The problem is
resolved.
3Check the...

2-160Service Manual 7510
Go Back Previous
Next
904.04 Sensor (2nd transfer roll retract HP) lag error
7Perform a print test.
Does the error continue?Replace the lower
printer engine card
assembly.
Go to “Lower
printer engine
card assembly
removal” on
page 4-91.
If the problem
persists, go to the
next step.
Problem solved.
8Perform a POR.
Does the error occur when the power is turned off/on?Contact the next
level of support.Problem solved.
Step Check Yes No
1Perform a POR.
Does the error occur...

Diagnostic information2-161
7510
Go Back Previous
Next
5Check the 2nd transfer roll retract motor for proper
connection.
Is the above component properly connected? Replace the 2nd
transfer roll retract
motor
. Go toReplace the
connection.
6Perform a print test.
Does the error continue?Replace the lower
printer engine card
assembly.
Go to “Lower
printer engine
card assembly
removal” on
page 4-91.
Problem solved.
7Perform a POR.
Does the error occur when the power is turned off/on?Replace the...

2-162Service Manual 7510
Go Back Previous
Next
904.05 Sensor (CMY transfer roll retract HP) late error
Step Check Yes No
1Perform a POR.
Does the error occur when the power is turned off/on?Go to step 2. Perform several
print tests.
If the problem
remains, go to
step 2.
2Did the error occur following a developer unit replacement? Verify the
developers are
installed correctly.
See “Developer
unit assembly
removal” on
page 4-63. Go to the next
step.
3Check to ensure that the transfer belt lift...

Diagnostic information2-163
7510
Go Back Previous
Next
5Do the PC units easily slide in and out of the machine? Go to the next
step.Replace any
damaged PC units
or any damaged
erase lamp
assembly. See
“PC cartridge
unit removal” on
page 4-54, “K
erase lamp
assembly
removal” on
page 4-76, or
“CMY erase lamp
assembly
removal” on
page 4-75 .
6Check that the transfer belt steering mechanism lock
packaging was fully removed. If not removed before the
transfer belt lever is lowered, the...

2-164Service Manual 7510
Go Back Previous
Next
904.06 Sensor (CMY transfer roll retract HP) lag error
Step Check Yes No
1Check the transfer belt unit assembly.
Is the above component properly installed?To to step 2 Properly reinstall
the transfer belt
unit assembly.
2Perform a POR.
Does the error occur when the power is turned off/on?Go to step 3. Perform several
print tests.
If the problem
remains, go to
step 3.
3Did the error occur following a developer unit replacement? Verify the
developers...
