Sony Vpl Ex130 Projector User Manual

4-162-930-11 (1)
© 2009 Sony Corporation
Data
Projector
Operating Instructions
Before operating the unit, please read this manual thoroughly
and retain it for future reference.
VPL-EX130

2WARNING
WARNING
To reduce the risk of fire or electric
shock, do not expose this apparatus
to rain or moisture.
To avoid electrical shock, do not open
the cabinet. Refer servicing to
qualified personnel only.
THIS APPARATUS MUST BE
EARTHED.
CAUTION
Danger of explosion if battery is incorrectly
replaced.
Replace only with the same or equivalent
type recommended by the manufacturer.
When you dispose of the battery, you must
obey the law in the relative area or country.
WARNING
When installing...

3WARNING
- Consult the dealer or an experienced radio/
TV technician for help.
You are cautioned that any changes or
modifications not expressly approved in this
manual could void your authority to operate
this equipment.
All interface cables used to connect
peripherals must be shielded in order to
comply with the limits for a digital device
pursuant to Subpart B of Part 15 of FCC
Rules.
This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1)...

4Table of Contents
Table of Contents
Precautions ......................................... 5
Notes on Installation and Usage  ........ 6
Overview
About the Supplied Manuals .............. 9
Included Attachments  ........................ 9
Location and Function of Controls  .. 10
Top/Right Side/Front  .................. 10
Rear/Bottom ............................... 10
Control Panel  .............................. 12
Connector Panel  ......................... 14
Remote Commander ................... 15...

5Precautions
Precautions
Safety
 Check that the operating voltage of your
unit is identical with the voltage of your
local power supply. If voltage adaptation is
required, consult with qualified Sony
personnel.
 Should any liquid or solid object fall into
the cabinet, unplug the unit and have it
checked by qualified personnel before
operating it further.
 Unplug the unit from the wall outlet if it is
not to be used for several days.
 To disconnect the cord, pull it out by the
plug. Never pull...

6Notes on Installation and Usage
 If you rub on the cabinet with a stained
cloth, the cabinet may be scratched.
 If the cabinet is in contact with a rubber or
vinyl resin product for a long period of
time, the finish of the cabinet may
deteriorate or the coating may come off.
LCD data projector
This LCD data projector is manufactured
using high-precision technology. You may,
however, see tiny black points and/or bright
points (red, blue, or green) that appear
continuously on the LCD data...

7Notes on Installation and Usage
Hot and humid
 Avoid installing the unit in a location
where the temperature or humidity is very
high, or the temperature is very low.
 To avoid moisture condensation, do not
install the unit in a location where the
temperature may rise rapidly.
Locations subject to direct cool or
warm air from an air-conditioner
Installing the projector in such a location
may cause a malfunction of the unit due to
moisture condensation or a rise in
temperature.
Near a heat or...

8Notes on Installation and Usage
Do not block the ventilation holes
Avoid using a thick-piled carpet or anything
that covers the ventilation holes (exhaust/
intake); otherwise, internal heat may build
up.
Do not place a blocking object just
in front of the lens
Do not place any object just in front of the
lens that may block the light during
projection. Heat from the light may damage
the object. Use the PIC MUTING key to cut
off the picture.
Do not use the Security bar for
transporting or...

Overview
9About the Supplied Manuals / Included Attachments
BOverview
About the Supplied
Manuals
The following manuals are supplied with the
projector.
Manuals
Quick Reference Manual (separately
printed manual)
This manual describes basic operations for
projecting pictures after you have made the
required connections. It also describes
important precautions for safe handling and
use of this projector.
Operating Instructions (on the CD-
ROM) (this manual)
This Operating Instructions describes the...

10Location and Function of Controls
Location and Function of Controls
Top/Right Side/Front
Rear/Bottom
24
5
6 1
3
78 90qa
qs qfqd qg qh qj
