Sony Vpl Cx85 Projector User Manual

21 GBConnecting the Projector
Setting Up and Projecting
your computer to XGA mode for the external
monitor.
 If you set your computer, such as a notebook
type, to output the signal to both your
computer’s display and the external monitor,
the picture of the external monitor may not
appear properly. Set your computer to output
the signal to only the external monitor.
For details, refer to the computer’s
operating instructions supplied with your
computer.
On the USB function
When connecting the...

GB 22Connecting the Projector
This section describes how to connect the
projector to a VCR.
For more information, refer to the
instruction manuals of the equipment you
are connecting.
To connect to a video or S video
output connector

1Stereo audio connecting cable (not supplied)
(Use a no-resistance cable.)
2Video cable (not supplied) or S-Video cable
(not supplied)
To connect to a video GBR/
Component output

1Stereo audio connecting cable (not supplied)
(Use a no-resistance cable.)
2SMF-402...

23 GBProjecting
Setting Up and Projecting
Projecting
1Plug the AC power cord into a wall
outlet, then connect all equipment.
The ON/STANDBY indicator lights in
red and the projector goes into standby
mode.
2Press the I / 1 key.
The ON/STANDBY indicator lights in
green and the Intelligent Auto-setup
starts.  The lens protector opens, and the powered tilt adjuster rises and stops at
the previously adjusted position.
When the projector is turned on, the
Startup screen is projected.
For details on...

GB 24Projecting
 If “Auto Input Search” is set to “On,” the
projector searches for the signals from
the connected equipment and displays
the input channel where the input signals
are found.
For details, see “Auto Input Search”
on page 37.
 The Smart APA is effective for the input
signal from a computer only.
5Switch the equipment to be connected
to output to the projector.
Depending on the type of your
computer, for example a notebook, or an
all-in-one LCD type, you may have to
switch the...

25 GBProjecting
Setting Up and Projecting
To adjust using the Remote
Commander
Press the TILT/KEYSTONE key on the
Remote Commander to display the Side
Shot menu (horizontal trapezoidal
distortion/H keystone correction) and
adjust the tilt using the M/m/

GB 26Selecting the Menu Language
BConvenient Function
Selecting the Menu
Language
You can select one of thirteen languages for
displaying the menu and other on-screen
displays. The factory setting is English.
To change the menu language, proceed as
follows:
1Plug the AC power cord into a wall
outlet.
2Press the I / 1 key to turn on the
projector.
3Press the MENU key.
The menu appears.
The menu presently selected is shown as
a yellow button.
4Press the M or m key to select the
MENU SETTING menu,...

27 GBSecurity Lock
Convenient Function
Security Lock
The projector is equipped with a security
lock function. When you turn the power of
the projector on, you are required to input
the previously set password. If you do not
input the correct password, you will not be
able to project the picture.
You will not be able to use the projector if you
forget your password and the password
administrator is not available. Be please aware
that using the security lock can prevent valid
usage in such cases....

GB 28Other Functions
4Turn the main power off and
disconnect the AC power cord.
The security lock is set to on, then it
becomes effective. The screen for
entering the password is displayed when
the power is turned on the next time.
Security certification
When the screen for entering the password is
displayed, enter the password that was set. If
you fail to enter the correct password after
three tries, the projector cannot be used. In
this case, press the I / 1 key to turn off the
power.
To...

29 GBOther Functions
Convenient Function
* Also available when not using the Air Shot.
If there is any obstruction between the
presentation tool and the remote control
detector on the projector, the presentation tool
may not function properly.
If you are leaving the conference room
immediately, turn the projector off, and then,
after the lens protector closes and the
powered tilt adjuster is put away in the
projector, you can unplug the AC power
cord. After the AC power cord is unplugged,
the...

GB 30Other Functions
Use the arrow key (M/m/
