11 GBFeatures
Overview
Security Functions
Security lock
This function makes it possible to project no
picture on the screen unless the required
password is entered when the projector is
turned on.
Panel key lock
This function locks all the operation keys on
the control panel of the projector, allowing
use of the keys on the Remote Commander.
This prevents the projector from operating
incorrectly....

GB 12Location and Function of Controls
Location and
Function of Controls

1Control panel
For details, see “Control Panel” on
page 13.
2Lens protector (lens cover)
The lens protector automatically opens
when the power is turned on.
3Powered tilt adjuster
4Front remote control detector
5Ventilation holes (exhaust)
6Access lamp
Lights during access to the Memory
Stick.
Do not remove the Memory Stick while
the access lamp is lit.
7Memory Stick slot
The Memory Stick can be inserted.
Never insert an...

13 GBLocation and Function of Controls
Overview
For details, see “Cleaning the Air
Filter” on page 43.
qhSecurity lock
Connects to an optional security cable
(Kensington’s).
Web page address:
http://www.kensington.com/
qjConnector/Connector Panel
For details, see “Connector Panel” on
page 14.
1I / 1  (on/standby) key
Turns on the projector when the
projector is in standby mode. The ON/
STANDBY indicator around the I / 1
key lights in green when the power is
turned on.
2ON/STANDBY indicator...

GB 14Location and Function of Controls
For details on the I/1 indicators, see
page 25.
3INPUT key
4TILT adjustment key
For details, see “Projecting” on
page 23.
5MENU key
Displays the on-screen menu. Press
again to clear the menu.
6ENTER/Arrow(f/F/g/G) keys
Enter the settings of items in the menu
system.
Select the menu or make various
adjustments.
7FOCUS +/– keys
Adjusts the picture focus.
8ZOOM +/– keys
Adjusts the picture size.
9SIDE SHOT +/– key
Adjusts the horizontal trapezoidal
distortion/H...

15 GBLocation and Function of Controls
Overview
2AC IN socket
Connects the supplied AC power cord.
3AUDIO (stereo minijack)
connector (common INPUT A/B)
When listening to sound output from the
computer, connect to the audio output of
the computer.
4USB connector (USB plug for
upstream, 4-pin)
Connect to the USB connector of a
computer. When you connect the
projector to the computer, you can
control the mouse function with the
supplied Remote Commander.
5VIDEO IN (Video input)
connector
Connect...

GB 16Location and Function of Controls
1 I / 1 (on/standby) key
2MUTING keys
Cut off the picture and sound.
PIC: Cuts off the picture. Press again
to restore the picture.
AUDIO: Press to temporarily cut off
the audio output from the speaker, and
the output on the AUDIO jack in the
OUTPUT section. Press again or press
VOLUME + key to restore the sound.
3INPUT key
4TILT/KEYSTONE (Vertical/
horizontal trapezoidal distortion
correction) key
Adjusts the tilt of the projector, or the...

17 GBLocation and Function of Controls
Overview
w;COMMAND ON/OFF switch
When this switch is set to OFF, no key
on the Remote Commander function.
This saves battery power.
wa Infrared transmitter
To install batteries
1Push and slide to open the lid, then
install the two size AA (R6) batteries
(supplied) with the correct polarity.
2Replace the lid.
When projecting the picture using the Air
Shot, you can control the presentation file
made by Microsoft PowerPoint.
1Laser transmitter
2LASER key
Emits a...

GB 18Location and Function of Controls
To install batteries
Notes on laser beam
 Do not look into the laser transmitter.
 Do not aim the laser at people.
Notes on Remote Commander/
Presentation tool operation
 Make sure that nothing obstructs the
infrared beam between the Remote
Commander/Presentation tool and the
remote control detector on the projector.
Direct the Remote Commander/
Presentation tool toward the front or rear
remote control detector.
 The operation range is limited. The shorter...

19 GBInstalling the Projector
Setting Up and Projecting
BSetting Up and Projecting
Installing the Projector
The distance between the lens and the screen varies depending on the size of
the screen. Use the following table as a guide.
There may be a slight difference between the actual value and the design value shown
in the table above.
For details on installation, see “Installation Diagram” on page 56.
Unit: m (feet)
Screen
size
(inches)40 60 80 100 120 150 180 200 250 300
Minimum
Distance1.2...

GB 20Connecting the Projector
Connecting the
Projector
When you connect the projector,
make sure to:
 Turn off all equipment before making any
connections.
 Use the proper cables for each connection.
 Insert the cable plugs firmly; loose
connections may increase noise and
reduce performance of picture signals.
When pulling out a cable, be sure to pull it
out from the plug, not the cable itself
When connecting to a wireless LAN by using
the Air Shot, see “Operating Instructions for
Air Shot”...
