Sony Vegas 5 Manual

CHP. 13USING VIDEO FX, COMPOSITING, AND MASKS
229
6.In the Video Event FX window, click the Eyedropper button
( ). The cursor changes to an eyedropper icon.
7.Draw (click and drag) a small rectangular selection area
around the color(s) to key out. Although you can select the
color range from just about anywhere, the Video Preview
window is the best location.
Note: Other effects that can change the color of the event
should be bypassed when using the Eyedropper tool.
8.Click the Split Screen View...

230
USING VIDEO FX, COMPOSITING, AND MASKSCHP. 13

14
CHP. 14ADDING VIDEO TRANSITIONS AND MOTION
CHAPTER231
Adding Video
Transitions and
Motion
Want something other than a cut or crossfade between video events? Vegas® software provides a wide
variety of transitions you can add to your project. This chapter also covers track motion and keyframe
animation, which allows you to automate video effects, media generators, cropping, panning, and more.
Understanding basic transitions
Transitions occur between two video events. Most professional productions,...

232
ADDING VIDEO TRANSITIONS AND MOTIONCHP. 14
Adding a transition
1.Insert a video event onto the timeline.
2.Insert another event so that it overlaps the first to create an
automatic crossfade.
3.In the Transitions window, browse for a transition effect. If the
Transitions window is not visible, choose
Transitions from the
View menu.
4.Drag the effect onto the crossfade between the two events.
Note: The duration of a transition is automatically
determined by the amount of overlap between the two...

CHP. 14ADDING VIDEO TRANSITIONS AND MOTION
233
Adding a transition to all selected events
If you tend to use the same transitions often, you can save yourself some time by adding a transition to all
selected events at once.
1.Select the events where you want to add the transition.
2.From the View menu, choose Transitions to display the
Transitions window.
3.Select a transition from the list on the left side of the window.
The thumbnail images on the right side of the window represent
each of the...

234
ADDING VIDEO TRANSITIONS AND MOTIONCHP. 14
3.Add points and adjust the fade curves as desired. For more information, see Using the Envelope Edit tool on
page 128.
In the following example, the transition starts, progresses to 50%, reverses direction, and then finishes.
Understanding track layers
If you want, you can view and modify transitions in an A/B roll
mode. Right-click the track header and choose
Expand Track
Layers
 from the shortcut menu to expand the track to reveal
three layers within...

CHP. 14ADDING VIDEO TRANSITIONS AND MOTION
235
The duration of the newly inserted transition event is determined by the Cut-to-overlap conversion time set in
the
Editing tab of the Preferences dialog. To access this dialog, choose Preferences from the Options menu.
Note: There must be enough media in the respective events
to cover the transition (e.g., the end of the first event must
not be the end of the media file).
Tip: You can also convert cuts between audio events to
crossfades. Click the cut...

236
ADDING VIDEO TRANSITIONS AND MOTIONCHP. 14
Modifying a transition
All of the transitions include several presets that create standard transitions. If a preset doesn’t meet your
needs, you can customize a transition to suit your taste.
Tip: You can also animate the parameters of a transition with
keyframes. For more information, see Using keyframe
animation on page 237.
1.Click the Transition Properties button
( ) on the transition or right-click the
transition and choose
Tr a n s i t i o n...

CHP. 14ADDING VIDEO TRANSITIONS AND MOTION
237
Using keyframe animation
Keyframe animation is a technique that computer artists
use to quickly make complex animated sequences.
Instead of drawing every frame of a title scrolling in from
top to bottom by hand, an animator simply has to set a
starting and ending position for the animation and let the
computer interpolate the intermediate frames. The
animation pictured on the right has three keyframes: a
starting, middle, and ending keyframe. More...

238
ADDING VIDEO TRANSITIONS AND MOTIONCHP. 14
Adding keyframes
Every effect has a starting keyframe at the beginning (left side) of the keyframe controller. This sets the
initial parameters for the effect. In order to animate the effect, you must add another keyframe to the effect
and change some of the parameters. When you first add a new keyframe, it has the same settings (for the
transition, effect, pan/crop, etc.) as the first keyframe. You can then modify the settings of the new keyframe
to...
