Sony Vegas 5 Manual

16
CHP. 16SAVING, RENDERING, AND PRINTING PROJECTS
CHAPTER269
Saving, Rendering,
and Printing Projects
Vegas® software allows you to save and render projects into many different multimedia formats. When you
render your Vegas project, the project itself is not altered, but rather can be rendered in any number of
different formats.
This chapter explains saving a project and using the Save As and Render As functions. In addition, you will
find reference information for the rendering options available....

270
SAVING, RENDERING, AND PRINTING PROJECTSCHP. 16
Creating a copy of a project (using Save As...)
After you have been working with your project, you can use the Save As command in the File menu to create
a copy of the small project file with a different name. Since multimedia projects can be very complex, and
since Vegas project files are so small, saving a number of different versions of a project is a low-risk way to try
new techniques.
1.From the File menu, choose Save As. The Save As dialog...

CHP. 16SAVING, RENDERING, AND PRINTING PROJECTS
271
Autosaving a project
A backup copy of your project is automatically saved every five minutes. If your system crashes, you are
prompted to open the backup file the next time you start the program.
Backup files are saved in the location specified in the
Temporary files folder box on the General tab of the
Preferences dialog. Files are saved with the .autosave.veg extension and are deleted when you close Vegas
software.
If you prefer not to autosave...

272
SAVING, RENDERING, AND PRINTING PROJECTSCHP. 16
6.Select any check boxes as needed:
Select the
Render loop region only check box to render only the portion of your project within the loop
selection.
Select the
Stretch video to fill output frame size (do not letterbox) check box to adjust the aspect ratio so the
output frame is filled on all edges. Clear the check box to maintain the current aspect ratio and add
black borders to fill the extra frame area (letterbox). This option is useful when...

CHP. 16SAVING, RENDERING, AND PRINTING PROJECTS
273
More about the MPEG format
MPEG renders can sometimes take more time than renders with some other formats. MPEG video files can
be played back on most computer systems. MPEG video files can also be burned to CDs or DVDs for
playback in standalone VCD, SCVD, and DVD players. Sony Pictures Digital cannot guarantee the
compatibility of MPEG files with VCD/DVD authoring software or VCD, SCVD, and DVD standalone
players. Consult your specific authoring...

274
SAVING, RENDERING, AND PRINTING PROJECTSCHP. 16
Internet
When video on the Internet is discussed, people almost always mean streaming. There are two streaming
media formats that come with Vegas software: RealMedia and Windows Media Format. There is nothing
particularly magical about streaming video, and the three rules of creating video files for the Internet are as
follows: compress, compress, and compress. The smaller the file size the better, and this inevitably results in a
loss of quality....

CHP. 16SAVING, RENDERING, AND PRINTING PROJECTS
275
Customizing the rendering process
Every media file format has different variables and controls. You can use a template to automatically
configure a particular format for a particular destination.
You can also choose to create custom settings for your render by clicking
Custom. Once you have customized
the settings, you can create your own template so that you can reuse the custom settings at a later time.
Customizing the Render As settings
1.From...

276
SAVING, RENDERING, AND PRINTING PROJECTSCHP. 16
Saving custom settings as a template
You can save customized rendering settings for future use. One of the most important reasons to save a new
template is to save the specific compression codec used to create the final media file, since this is not
predetermined by the project properties.
1.Modify the parameters in the Custom Template dialog.
Note: When determining bit rates, 1K=1024.
2.In the Te m p l a t e drop-down list, enter a name for the new...

CHP. 16SAVING, RENDERING, AND PRINTING PROJECTS
277
Frame rate
Frame rate is important in determining the quality and size of the final media file. The appropriate frame rate
is determined by the final destination of the movie. See your video capture card’s manual for more
information. The final rendered multimedia file can have a different frame rate from the project itself.
Field order
Video that is displayed on a television monitor is interlaced. This means that every frame of video is actually...

278
SAVING, RENDERING, AND PRINTING PROJECTSCHP. 16
Create an OpenDML (AVI version 2.0) compatible file
Select this check box if you want to save your file as an OpenDML file. OpenDML files allow you to create
files that are limited in size only by the format of your hard disk: 2GB using FAT32 or 4GB using NTFS.
Audio tab
Include audio
Select this check box to include the audio stream and enable the remaining fields on the dialog. If you do not
want to include the audio stream, clear this check box....
