Page 141

FRONT WHEEL
4-8
EAS21960
ASSEMBLING THE FRONT WHEEL
1. Install:
Wheel bearings
Oil seals

a. Install the new wheel bearings and oil seals in
the reverse order of disassembly.
CAUTION:
EC2C01010
Do not contact the wheel bearing inner race
“1” or balls “2”. Contact should be made
only with the outer race “3”.
NOTE:
Use a socket “4” that matches the diameter of
the wheel bearing outer race and oil seal.

EAS21970...

Page 142

FRONT WHEEL
4-9
b. Turn the front wheel 90° so that the heavy
spot is positioned as shown.
c. If the heavy spot does not stay in that posi-
tion, install a heavier weight.
d. Repeat steps (b) and (c) until the front wheel
is balanced.

4. Check:
Front wheel static balance

a. Turn the front wheel and make sure it stays at
each position shown.
b. If the front wheel does not remain stationary
at all of the positions,...

Page 143

FRONT WHEEL
4-10
CAUTION:
EC2C01015
Before tightening the wheel axle, push down
hard on the handlebar several times and
check if the front fork rebounds smoothly.
NOTE:
Lubricate the front wheel axle bolt mating surfac-
es with lithium-soap-based grease.

a. Insert the front wheel axle from the right side
and tighten it with the front wheel axle bolt
from the left side to 91 Nm (9.1 m·kg, 66 ft·lb)
without performing temporary tightening.
b. In the order...

Page 144

REAR WHEEL
4-11
EAS22020
REAR WHEEL
Removing the rear wheel
Order Job/Parts to remove Q’ty Remarks
NOTE:
Place the vehicle on a suitable stand so that the rear wheel is elevated.
1 Rear brake caliper 1
2 Drive chain adjusting locknut 2 Loosen.
3 Drive chain adjusting bolt 2 Loosen.
4 Rear wheel axle nut 1
5 Washer 1
6 Rear wheel axle 1
7 Rear wheel 1
8 Brake pad spring 1
9 Rear brake caliper bracket 1
For installation, reverse the removal proce-
dure.

Page 145

REAR WHEEL
4-12
Removing the rear brake disc and rear wheel sprocket
Order Job/Parts to remove Q’ty Remarks
1 Rear brake disc 1
2 Rear wheel sprocket 1
3 Collar 1
4Dust cover 1
5 Oil seal 1
6 Bearing 1
7 Rear wheel drive hub 1
8 Rear wheel drive hub damper 6
9Dust cover 1
10 Collar 1
For installation, reverse the removal proce-
dure.

Page 146

REAR WHEEL
4-13
Disassembling the rear wheel
Order Job/Parts to remove Q’ty Remarks
1 Collar 1
2 Bearing 1
3Spacer 1
4 Oil seal 1
5 Circlip 1
6 Bearing 1
For assembly, reverse the disassembly pro-
cedure.

Page 147

REAR WHEEL
4-14
EAS22040
REMOVING THE REAR WHEEL
1. Stand the vehicle on a level surface.
WARNING
EWA13120
Securely support the vehicle so that there is
no danger of it falling over.
NOTE:
Place the vehicle on a suitable stand so that the
rear wheel is elevated.
2. Remove:
Rear brake caliper “1”
NOTE:
Do not depress the brake pedal when removing
the brake caliper.
3. Remove:
Rear wheel axle nut “1”
Rear wheel axle “2”
Rear wheel
NOTE:
Push the rear wheel forward and remove the
drive chain from...

Page 148

REAR WHEEL
4-15
2. Replace:
Rear wheel sprocket

a. Remove the self-locking nuts and the rear
wheel sprocket.
b. Clean the rear wheel drive hub with a clean
cloth, especially the surfaces that contact the
sprocket.
c. Install the new rear wheel sprocket.
NOTE:
Tighten the self-locking nuts in stages and in a
crisscross pattern.

EAS22140
ASSEMBLING THE REAR WHEEL
1. Install:
Wheel bearings
Oil seals
Refer to...

Page 149

REAR WHEEL
4-16
4. Adjust:
Drive chain slack
Refer to “ADJUSTING THE DRIVE CHAIN
SLACK” on page 3-25.
5. Install:
Rear brake caliper
WARNING
EWA13500
Make sure the brake hose is routed properly.

Drive chain slack
35.0–45.0 mm (1.38–1.77 in)
T R..
Rear brake caliper bolt (M12)
27 Nm (2.7 m·kg, 19 ft·lb)
Rear brake caliper bolt (M8)
22 Nm (2.2 m·kg, 16 ft·lb)
LOCTITE
®

Page 150

FRONT BRAKE
4-17
EAS22210
FRONT BRAKE
Removing the front brake pads
Order Job/Parts to remove Q’ty Remarks
The following procedure applies to both of
the front brake calipers.
1 Reflector assembly 1
2 Brake hose holder 1
3 Front brake caliper 1
4 Brake pad clip 2
5 Brake pad pin 1
6 Brake pad spring 1
7 Front brake pad 2
For installation, reverse the removal proce-
dure.
