Samsung Gear VR 2016 User Manual








N

ote: Ensure that the connector is fully inserted into the mobile
device’s USB port. The device makes a sound when properly
connected.
Caution: Do not forcefully insert the connector into the mobile
device as this may damage the connector. Improper installation can
scratch the mobile device.
4.	  Insert the mobile device into the center of the Gear VR and gently
push the mobile device until it
locks into place (2). The device holder (right) will return to the
previous...



33
22
11
5. Verify the orientation of the mobile device.
Caution: If you insert the mobile device tilted to one side, it may
cause discomfort. In this case, the mobile device screen will not be
aligned properly to the lenses.
42





C

orrectly Mounted
Alignment
Device Holder (right)
Tabs
N

ote: Verify that your device volume is not set to silent. If the sound
is not emitted when you insert the connector into the mobile device,
the Gear VR did not recognize the connection. Carefully reconnect
the mobile device until you hear the sound.
Caution: Do not leave the Gear VR in direct sunlight. Exposure to
direct sunlight can damage the Gear VR and the connected mobile
device.
Getting Started  43










Installing Gear VR Software
You must install the Gear VR software in order to use the Gear VR.
When you connect the mobile device to the Gear VR for the �rst time,
the set up process automatically begins.
Note: Connect your mobile device to an active cellular network or
Wi-Fi connection before performing the setup process.
1.	 If using the device for the �rst time, go to www�oculus�com to
create an account and follow the...











6.
Read and agree to the health and safety warnings, and the terms
and conditions in the End User License Agreement (EULA), and
then tap  NEXT > IN S TA L L .
Note: During this initial process, you might be prompted to install
additional software or update your mobile device �rmware.
7.	  When prompted, tap  Sign In and enter your previously created
email and password.
8.	  Follow the onscreen prompts to con�gure your account.
9.	  When the...












Completing the Set Up Process
1.  Con�rm the mobile device is securely mounted into the Gear VR.
2.	  Read the displayed  Health & Safety Warning! information and
then use your head to position the onscreen Pointer (crosshair)
into the Oculus logo area to continue.
3.  Follow the prompts to learn how to:
• Position the cursor at desired locations.
• Use the Touchpad to make selections.
• Swipe forward and backward using the Touchpad.
• Swipe up and down.
• Use...








This menu contains items such as: Oculus Home, Passthrough
Camera, Reorient, Volume, and Brightness.
• A proximity sensor inside the Gear VR detects the position of your
face. When you wear the Gear VR, the screen will unlock and you
can then use the touchpad.
• The 3D viewing experience may vary depending on your visual
acuity.
• Unlock your mobile device before using the Gear VR.
• If the screen appears tilted or skewed while using the Gear VR,
take it off. Then, place...










Wearing the Gear VR
1.	 Align your face and the foam cushion and put on the Gear VR.
Caution: Do not walk or drive while
wearing the Gear VR. Always be aware
of your surroundings while using the
Gear VR to avoid injury to yourself or
others.
2.	  Secure the Gear VR to your head
with the straps and place it
comfortably over your face.
3.	 Adjust the length of the top head
strap and the main strap.
Note: The foam cushioning may get dirty and cause the foam...







Connecting a Headset
You can connect a headset or a Bluetooth headset to the mobile
device when using the Gear VR.
Note: Some audio jacks on headphones/earbuds may not �t properly
in your mobile device while mounted to the Gear VR.  If this is the
case, do not force the connector into the mobile device as this may
cause damage.
►


T
 o use a headset or a Bluetooth headset while using the Gear VR,
connect it to your mobile device before connecting the mobile
device...




Removing the Mobile Device
Remove the mobile device from the Gear VR when not in use.
1.	  Remove the protective cover (that aids in securing the mobile
device).
2.	  Carefully pull the device holder (right) outward (1), remove the
connected mobile device (2) by carefully sliding it outwards at an
angle, and then replace the front cover.
