Panasonic Network Camera Wv Sc384 Wv Sc385 Installation Guide

SymptomCause/solutionReference
pages
Live indicator keeps on
blinking orange approx. in 2
seconds intervals. 	•	 UPnP
TM error has occurred since the power is not supplied to the
router.
    Turn on the power of the router. Wait until the connections are
established.  −
	•	 An	error	has	occurred	during	the	port	update	by	the	UPnP	func- tion.
	•	 If	the	router	in	use	does	not	support	the	UPnP	function,	perform	 the port forwarding setting for the router. In addition, deactivate the
setting of auto...

SymptomCause/solutionReference
pages
Cannot access the camera. 	•	 Are	you	accessing	the	wrong	IP	address?

Check the connection as follows
    With the Windows command prompt,
    > ping "IP address of the camera"
    If there is reply from the camera, the connection is normal.
    If not, proceed either of the following.
	 •	 Reboot	 the	camera	 and	change	 the	IP	address	 by	using	 the
Panasonic  IP  setup  software  within  20  minutes  after  the
restart.
	 •	 Reboot	 the	camera...

About the live indicator
The live indicator will light or blink as follows depending on the camer\
a status.
Operation statusIndicator status
When the power is turned on Before the network
connection is establishedBlinks orange
When the network
connection is established Blinks orange → Blinks green → Lights green
During the standby or connection (Cable is not connected.) Lights orange
During the standby or connection (Cable is connected.) Lights green
During the upgrade process Blinks orange
During...

Specifications
• Basic
Power source: 12 V DC, PoE (IEEE802.3af compliant)
Power consumption:  WV-SC385: 12 V DC*:  1 A, PoE 48 V: 12 W/230 mA (Class 0 device)
    WV-SC384: 12 V DC*:  690 mA, PoE 48 V: 10 W/190 mA (Class 0 device)
    *  FOR UL LISTED MODEL(S), ONLY CONNECT 12 V DC CLASS 2 POWER
SUPPLY.
Ambient	operating	temperature:	 –10	°C	to	+50	°C	{14	°F	to	122	°F}
Ambient operating humidity:  Less than 90 % (no condensation)
Monitor output:  VBS: 1.0 V [p-p]/75	Ω,	composite	(BNC),	ø3.5	mm	mini	jack...

Auto slow shutter: Off (1/30 s), max. 2/30 s, max. 4/30 s, max. 6/30 s, max. 10/30 s, max. \
16/30 s
Color/BW (SC385):  On/ Off/ AUTO1/ AUTO2/ AUTO3
Simple black & white mode (SC384):  Off/Auto
White balance:  ATW1/ ATW2/ AWC
Digital noise reduction:  High/Low
Image stabilizer:  On/Off
Video analytics
  Face detection:  On/Off (with the XML notification setting)
Privacy zone:  WV-SC385: On/Off (up to 8 zones available)
    WV-SC384: On/Off (up to 2 zones available)
Camera title on screen:   On/Off
    Up...

Resolution (SC384): Aspect ratio: 4:3
    H.264 1280x960/ VGA(640x480)/ QVGA(320x240), max. 30 fps
    MPEG-4 VGA(640x480)/ QVGA(320x240), max. 30 fps
    JPEG (MJPEG) 1280x960/ VGA(640x480)/ QVGA(320x240), max. 30 fps
    Aspect ratio: 16:9
    H.264 1280x720/ 640x360/ 320x180, max. 30 fps
    JPEG (MJPEG) 1280x720/ 640x360/ 320x180, max. 30 fps
    * MPEG-4 is not supported.
Image compression method*
1 *2:  H.264/MPEG-4
     Image quality: Low/ Normal/ Fine
     Transmission type: Unicast/Multicast...

Standard accessories
Installation Guide (this document) ....................................1 pc.
Warranty card (NTSC model only)  ....................................1 pc.
CD-ROM*
1  ....................................................................... 1 pc.
Code label*2  .................................................................... 1 pc.
*1   The CD-ROM contains the operating instructions (PDFs) and different kinds of tool software programs.
*2   This label may be required for network...

38
Information for Users on Collection and Disposal of Old Equipment and us\
ed Batteries
These symbols on the products, packaging, and/or accompanying documents mean that used electric\
al and
electronic products and batteries should not be mixed with general household waste.
For proper treatment, recovery and recycling of old products and used batteries, please take them to applicable
collection points, in accordance with your national legislation and the Directives 2002/96/EC and 2006/66/EC.
By...
