NEC Neax 2400 Imx Ccis Features And Specifications

NEAX2400 IMX CCIS Features and Specifications
Page viNDA-24222, Issue 3
C-58Consultation Hold - All Calls - CCISXX→→X
C-94Call Forwarding Assignment - Attendant
- CCISXX→→N
C-163CCIS Networking via IPXX X
C-167Centralized Maintenance - CCISXX X
D-41Data Communication - CCISXN→NN
D-65Data Interface - Automatic Answer -
CCISXN→NN
D-66Data Line Security - CCISXN→NN
D-67Data Line Privacy - CCISXN→NN
D-68Data Privacy on Demand - CCISXN→NN
D-69Data Transparency - CCISXN→NN
D-70Deluxe Traveling Class Mark -...

NEAX2400 IMX CCIS Features and Specifications
NDA-24222, Issue 3
Page vii
F-12Flexible Numbering of Stations - CCISXX→→X
H-10D
Hands-free Answerback - D
term - CCISX—→—X
H-11House Phone - CCISXX→→X
H-12Hotline - CCISXN→XX
I-16Incoming Call Identification - CCISXX→→X
I-17Individual Attendant Access - CCISXX→→X*
I-18Inter-Position Transfer - CCISX—→——
L-25Look Ahead Routing - CCISXX→→X
L-29LDN Night Connection - CCISXX→→X
M-34Message Reminder - CCISXX→→N
M-34D
Message Reminder - D
term - CCISXX→→N...

NEAX2400 IMX CCIS Features and Specifications
Page viiiNDA-24222, Issue 3
M-67Message Center Interface - CCISXX E→X
N-15Night Connection - Fixed - CCISXX→→X
N-16Night Connection - Flexible - CCISXX→→X
N-37Name Display - System - CCISXX→→X
N-46Number Portability - CCISXX X
O-11Off-Hook Queuing - CCISXX→→X
O-12Outgoing Trunk Queuing - CCISXX→→N
P-28Paging Access - CCISXX→→X
R-22Restriction from Outgoing Calls - CCISXX→→X
S-52Serial Call - CCISXX→→N
S-53D
Service Display - D
term - CCISX—→—N...

NEAX2400 IMX CCIS Features and Specifications
NDA-24222, Issue 3
Page ix
Note 1:* This feature is available on the condition that the NEAX2000 IVS is the satellite office.
Note 2:** Only 2 modes of Day/Night are available for NEAX2000 IVS.
Note 3:Telephone numbers should be used for activating CCIS services through FCCS groups and a NEAX2000 IVS.
T-27Trunk Answer from Any Station - CCISXX→→X
U-5Uniform Numbering Plan - CCISXX→→X
V-7Voice Call - CCISXX→→X
NEAX2400 IMX CCIS Features (Continued)
LEGEND
X –...

NEAX2400 IMX CCIS Features and Specifications
Page xNDA-24222, Issue 3
This page is for your notes.

NEAX2400 IMX CCIS Features and Specifications
NDA-24222, Issue 3
Page 1
Networking with NEAX2400 IMX and NEAX2000 IVS
Purpose
(Series 7400 software enhancement) The following explains connectivity issues between a NEAX2400 IMX and
a NEAX2000 IVS. An FCCS Group consists of a network where multiple NEAX2400 IMXs are connected via
FCCS link.
Note: NEAX2400 IMX - NEAX2000 IVS connection is available only if the NEAX2000 IVS is the satellite office (requires
NEAX2 000  IVS  Series  2 000  or later s oft w...

NEAX2400 IMX CCIS Features and Specifications
Page 2NDA-24222, Issue 3
Service Conditions (cont’d)
2. A center FCCS group should be specified from among multiple FCCS groups in the network. It is the only
node allowed to assign and delete telephone numbers within the self FCCS group and the others.
3. The network consists of FCCS groups and NEAX2000 IVS systems within the range of 2 SPANs from
the center FCCS group, and within the range of 4 SPANs from end to end.
Interactions
1. PS Roaming and...

NEAX2400 IMX CCIS Features and Specifications
NDA-24222, Issue 3
Page 3
Asynchronous Data Switching - CCIS A-44
A-44 Asynchronous Data Switching - CCIS
General Description
The NEAX2400 IMX supports up to 19.2 Kbps asynchronous switched modemless data communication, from node
to node, in a CCIS network. An asynchronous Data Adapter is required for the Dterm, and an asynchronous Data
Module is used for non-voice applications.
Operating Procedure
To initiate a data call from a Dterm equipped with a Data...

NEAX2400 IMX CCIS Features and Specifications
Page 4NDA-24222, Issue 3
A-44 Asynchronous Data Switching - CCIS
Service Conditions
1. Data terminals up to 19.2 Kbps can be connected.
Note:
Additional hardware is required for 19.2 Kbps.
2. A data terminal can be a member of a Pilot Hunt group or a Circular Hunt group.
3. The calling and called DTEs must be code and speed compatible.
4. Keyboard dialing can only be utilized by a D
term/Data Adapter or asynchronous Data Module.
5. Additional hardware is...

NEAX2400 IMX CCIS Features and Specifications
NDA-24222, Issue 3
Page 5
Attendant Camp-On with Tone Indication - CCIS A-45
A-45 Attendant Camp-On with Tone Indication - CCIS
General Description
This service feature allows Inter-Office Attendant Camp-On for when the Attendant and the called party belong to
a different PBX in the CCIS network.
Operating Procedure
1. Stations (a) and (b) are talking through a CCIS line.
2. Subscriber (c) places a call to Node A through a CO line. An Attendant in Node A...
