Midway Cruis N Exotica Operations Manual For 39 Dedicated Game With Motion Seat

Diagnostics - 23
Main Menu
     Game Adjustments, continued
          Multi Player Free Races Menu
Multi Player Free Races
This determines whether or not multiple players win free races for top scores.  The setting range is:
-On:
-Off:
-Factory Setting:     Off
Main Menu
     Utilities
UTILITIES
To clear bookkeeping memory and reset factory defaults, select Utilities at the Main Menu. Press the
Volume Up or Volume Down button to highlight the Utilities option on the Main Menu, then press the Test
button....

Diagnostics - 24
Main Menu
     Utilities, continued
          Clear Credits Menu
Clear Credits
Press the Volume Up or Volume Down buttons to highlight the Clear Credits option on the Main Menu,
then press the Test button.  This returns all credit values to zero and removes credit amounts from
memory.
- Yes
- No
- Factory Setting: NO
Main Menu
     Utilities, continued
          Clear Game Audits Menu
Clear Game Audits
Press the Volume Up or Volume Down buttons to highlight the Clear Game Audits option...

Diagnostics - 25
Main Menu
     Calibrate Controls
CALIBRATE CONTROLS
To calibrate controls for optimum performance, select Calibrate Controls at the Main Menu.
CALIBRATE CONTROLS
TURN  WHEEL  LEFT
        PRESS THE TEST TO CONTINUE
TURN  WHEEL  RIGHT
       PRESS THE TEST TO CONTINUE
PRESS THE GAS PEDAL
       PRESS THE TEST TO CONTINUE
PRESS THE BRAKE PEDAL
       PRESS THE TEST TO CONTINUE
Press the Volume Up or Volume Down buttons to highlight the Calibrate Controls option on the Main
Menu, then...

Diagnostics - 26
NOTES




™















Service - 2
SAFETY INSTRUCTIONS
The following safety instructions apply to operators and service personnel.  Read these instructions
before servicing or preparing the Video Game Machine (VGM) for play.  Other safety instructions
appear throughout this manual.
DEFINITIONS OF SAFETY TERMS
♦
 DANGER
 indicates an imminent hazard.  If you fail to avoid this hazard, it WILL cause death or
serious injury.
♦
 WARNING
 indicates a potential hazard.  If you fail to avoid this hazard, it COULD cause death or...

Service - 3
WARNING: HAZARD TO EPILEPTICS.
A very small portion of the population has a condition which may cause them to experience
epileptic seizures or have momentary loss of consciousness when viewing certain kinds of
flashing lights or patterns that are present in our daily environment.  These persons may
experience seizures while watching some kinds of television pictures or playing certain video
games.  People who have not had any previous seizures may nonetheless have an undetected
epileptic...

Service - 4
SERVICING
Only qualified service personnel should perform maintenance and repairs. The product guidelines
apply to all operators and service personnel. Specific notes, cautions, and warnings appear throughout
the manual where they apply. We recommend that you read the SAFETY NOTICES section
thoroughly before beginning service. NOTE:
Always switch off power to the game machine before
servicing.
To service the Marquee…
Refer to Marquee Service illustration.
¾  Switch off the power to the game...

Service - 5
To service Blue Beacon Light…
Refer to Beacon Light Service and Marquee Service illustrations.
¾  Switch off the power to the game machine and unplug the AC line cord.
¾  Remove the mounting screws used to fasten the beacon light to the marquee housing. Set the screws
aside for reuse later.
¾  Lift the beacon light up from the housing enough to expose the cable connection. Disconnect the
cable and continue to lift the beacon light until it clears the marquee housing.
¾  Perform the desired...

Service - 6
To service the Fluorescent Lamp or Starter…
Refer to Marquee Service illustration.
¾  Switch off the power to the game machine and unplug the AC line cord.
¾  Lift open the Marquee Housing. Refer to service instructions for Marquee.
¾  Reach up inside the opening in the cabinet and remove the fluorescent lamp locks.
¾  Both the fluorescent tube and the starter require a quarter turn for removal. Grasp the tube or
starter, give it a quarter turn and pull it from its socket.
¾  Carefully place...
