dell latitude d505 series User Manual

System Components: Dell Latitude D505 Series Service Manual

1 display assembly
see Mini RSL 8speakers H1330
2 center control
cover H1371
9hard drive
see Mini RSL
3 palm rest (with
touch pad) D1482
10fan J1043
4 system board W334411microprocessor
see Mini RSL
5 computer base  12microprocessor thermal-
cooling assembly H1309
6 battery
see Mini RSL 13keyboard 1M709
7 reserve battery 3R45914display cable
Back to Contents Page

file:///F|/Service%20Manuals/Dell/Latitude/d505/system.htm (2 of 2) [2\...

Reserve Battery: Dell Latitude D505 Series Service Manual
Back to Contents Page
Reserve Battery
Dell™ Latitude™ D505 Series Service Manual
 CAUTION: Before working inside your Dell™ computer, read the safety
instructions in your System Information Guide.
 CAUTION: To prevent static damage to components inside your
computer, discharge static electricity from your body before you touch
any of your computers electronic components. You can do so by
touching an unpainted metal surface.
1.  Follow the...

Reserve Battery: Dell Latitude D505 Series Service Manual
1reserve battery cover 6R456
4.  Pull the reserve battery straight out of the computer base.
5.  Disconnect the reserve-battery cable connector from the battery connecto\
r.

1 battery connector
2 reserve battery 3R459
Back to Contents Page

file:///F|/Service%20Manuals/Dell/Latitude/d505/reserve.htm (2 of 2) [\
2/28/2004 8:13:45 AM]

Hard Drive: Dell Latitude D505 Series Service Manual
Back to Contents Page
Hard Drive
Dell™ Latitude™ D505 Series Service Manual
 CAUTION: If you remove the hard drive from the computer when the
drive is hot, do not touch the metal housing of the hard drive.
 CAUTION: Before working inside your computer, read the safety
instructions in your System Information Guide.
NOTICE: To prevent data loss, shut down your computer before removing the
hard drive. Do not remove the hard drive while the computer...

Hard Drive: Dell Latitude D505 Series Service Manual

1 M2.5 x 5-mm screws (2) 63PDH
NOTICE: When the hard drive is not in the computer, store it in protective
antistatic packaging. See Protecting Against Electrostatic Discharge i\
n your
System Information Guide.
3.  Slide the hard drive out of the computer.
4.  Remove the new drive from its packaging.
Save the original packaging to use when storing or shipping the hard dri\
ve.
NOTICE: Use firm and even pressure to slide the drive into place. If...

Hard Drive: Dell Latitude D505 Series Service Manual
7.  Use the Drivers and Utilities CD to install the drivers and utilities for your computer.
Back to Contents Page

file:///F|/Service%20Manuals/Dell/Latitude/d505/hdd.htm (3 of 3) [2/28\
/2004 8:13:46 AM]

Bluetooth™ Card: Dell Latitude D505 Series Service Manual
Back to Contents Page
Bluetooth™ Card
Dell™ Latitude™ D505 Series Service Manual
 CAUTION: Before performing the following procedures, read the safety
instructions in your System Information Guide.
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist
grounding strap or by periodically touching an unpainted metal surface (\
such as
the back panel) on the computer.
1.  Follow the instructions in
Preparing to Work Inside...

Bluetooth™ Card: Dell Latitude D505 Series Service Manual

1 Bluetooth card 2U381
2 system board connector
3 Bluetooth card connector
4 Bluetooth cable
Back to Contents Page

file:///F|/Service%20Manuals/Dell/Latitude/d505/blue.htm (2 of 2) [2/2\
8/2004 8:13:46 AM]

Keyboard: Dell Latitude D505 Series Service Manual
Back to Contents Page
Keyboard
Dell™ Latitude™ D505 Series Service Manual
 CAUTION: Before performing the following procedures, read the safety
instructions in your System Information Guide.
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist
grounding strap or by periodically touching an unpainted metal surface (\
such as
the back panel) on the computer.
1.  Follow the instructions in
Preparing to Work Inside the Computer....

Keyboard: Dell Latitude D505 Series Service Manual
1displaysee Mini RSL
2 center control cover H1371
3 palm rest (with touch pad) D1482
3.  Remove the center control cover:  a.  Open the display all the way (180 degrees) so that it lies flat agains\
t your work surface.
b.  Starting on the right side of the computer, use a plastic scribe to pry \
up  the center control cover. Lift it away from the computer, and lay it asi\
de.

1 center control cover H1371
4.  Remove the keyboard:...
