Acer Ferrari 1200 Service Guide

Chapter 141
Temperature Range( C)
Operating
Storage (shipping)0 to +50
-20 to +60
AC Adaptor
ItemSpecification
Input rating 90V AC to 264V AC, 47Hz to 63Hz
Maximum input AC current 1.7A
Inrush current  220A@115VAC
220A@230VAC
Efficiency 82% min. @115VAC input full load
System Power Management
ACPI modePower Management
Mech. Off (G3) All devices in the system are turned off completely.
Soft Off (G2/S5) OS initiated shutdown. All devices in the system are turned
off completely.
Working (G0/S0) Individual...

42Chapter 1

Chapter 243
BIOS Setup Utility
The BIOS Setup Utility is a hardware configuration program built into your computer’s BIOS (Basic Input/
Output System).
Your computer is already properly configured and optimized, and you do not need to run this utility. However, if
you encounter configuration problems, you may need to run Setup. Please also refer to Chapter 4
Troubleshooting when problem arises.
To activate the BIOS Utility, press F2 during POST (when “Press  to enter Setup” message is prompted
on the...

44Chapter 2
Navigating the BIOS Utility
There are six menu options: Information, Main, Advanced, Security, Boot, and Exit.
Follow these instructions:
•To choose a menu, use the left and right arrow keys.
•To choose an item, use the up and down arrow keys.
•To change the value of a parameter, press F5 or F6.
•A plus sign (+) indicates the item has sub-items. Press Enter to expand this item.
•Press Esc while you are in any of the menu options to go to the Exit menu.
•In any menu, you can load default...

Chapter 245
Information
The Information screen displays a summary of your computer hardware information.
NOTE: The system information is subject to different models.
ParameterDescription
CPU Type This field shows the CPU type and speed of the system.
CPU Speed This field shows the speed of the CPU.
IDE0 Model Name This field shows the model name of HDD installed on primary IDE master.
IDE0 Serial Number This field displays the serial number of HDD installed on primary IDE master.
ATAPI Model Name This...

46Chapter 2
Main
The Main screen allows the user to set the system time and date as well as enable and disable boot option
and recovery.
NOTE: The screen above is for your reference only. Actual values may differ.
Phoenix TrustedCore(tm) Setup Utility
Main
Item Specific Help
, , or
 selects field. System Time:
System Date:
System Memory:
Extended Memory:
Video Memory:
Quiet Boot:
Network Boot:
F12 Boot Menu:
D2D Recovery:
F1
EscHelp
ExitSelect Item
Select Menu
Change Values
Select Sub-Menu -/+
EnterF9...

Chapter 247
The table below describes the parameters in this screen. Settings in boldface are the default and suggested
parameter settings.
NOTE: The sub-items under each device will not be shown if the device control is set to disable or auto. This is
because the user is not allowed to control the settings in these cases.
ParameterDescriptionFormat/Option
System Time Sets the system time. The hours are displayed
with 24-hour format.Format: HH:MM:SS
(hour:minute:second) System Time
System Date Sets...

48Chapter 2
Advanced
The Advanced screen allows the user to set the serial, infrared and parallel ports.
The table below describes the parameters in this screen. Settings in boldface are the default and suggested
parameter settings.
ParameterDescriptionFormat/Option
Serial Port Enable or Disable the serial port
Option:
Enabled or Disabled
Infrared Port Enable or Disable the infrared port
Option:
Enabled or Disabled
Parallel Port Enable or Disable the parallel port
Option:
Enabled or Disabled
Mode...

Chapter 249
Security
The Security screen contains parameters that help safeguard and protect your computer from unauthorized
use.
NOTE: Please refer to “Remove HDD/BIOS Password” section if you need to know how to remove HDD/BIOS
Password.
Phoenix TrustedCore(tm) Setup Utility
Main
Item Specific Help
Supervisor Password
controls access of the
whole setup utility.
Itcanbeusedtoboot
up when Password on
boot is enabled. Supervisor Password s:
User Password s:
:
Set User Password
Set Password
Password on...

50Chapter 2
The table below describes the parameters in this screen. Settings in boldface are the default and suggested
parameter settings.
NOTE: When you are prompted to enter a password, you have three tries before the system halts. Don’t forget
your password. If you forget your password, you may have to return your notebook computer to your
dealer to reset it.
Setting a Password
Follow these steps as you set the user or the supervisor password:
1.Use the w andy keys to highlight the Set Supervisor...
