Acer Ferrari 1200 Service Guide
Here you can view all the pages of manual Acer Ferrari 1200 Service Guide. The Acer manuals for Notebook are available online for free. You can easily download all the documents as PDF.
Page 41
Chapter 131 Using the System Utilities Acer GridVista (dual-display compatible) NOTE: This feature is only available on certain models. To enable the dual monitor feature of the notebook, first ensure that the second monitor is connected, then select Start, Control Panel, Display and click on Settings. Select the secondary monitor (2) icon in the display box and then click the check box Extend my windows desktop onto this monitor. Finally, click Apply to confirm the new settings and click OK to...
Page 42
32Chapter 1 NOTE: Please ensure that the resolution setting of the second monitor is set to the manufacturers recommended value. Launch Manager Launch Manager allows you to set the four easy-launch buttons located above the keyboard. You can access the Launch Manager by clicking on Start > All Programs > Launch Manager to start the application. Norton Internet Security Norton Internet Security is an anti-virus utility that can protect against viruses, keeping your data safe and secure. How do I check...
Page 43
Chapter 133 3.Select Run Scan to scan your system. 4.When the scan is complete, review the results of the scan. NOTE: For optimal security, run a Full System Scan when scanning your computer for the first time. You can schedule customized virus scans that run unattended on specific dates and times or at periodic intervals. If you are using the computer when the scheduled scan begins, it runs in the background so that you do not have to stop working. For more information refer to the Norton Internet...
Page 44
34Chapter 1 Hardware Specifications and Configurations Throttling 50%: On= 99 C; OFF=93 C Processor ItemSpecification CPU type AMD Turion™ X2 Dual-Core Mobile processor RM-70/RM-72/RM- 74/RM-75 (1000KB L2 cache, 2.0/2.1/2.2/2.2 GHz), supporting AMD HyperTransport™ 3.0 technology AMD Turion™ X2 Ultra Dual-Core Mobile Processor ZM-80/ZM- 82/ZM-84/ZM-85/ZM-86/ZM-87 (2000KB L2 cache, 2.1/2.2/2.3/23/ 2.4/2.4 GHz), supporting AMD HyperTransport™ 3.0 technology Core logic AMD RS780M+SB700 CPU package Socket...
Page 45
Chapter 135 OS shut down at 105 C; H/W shot down at 110 .C BIOS ItemSpecification BIOS vendor Phoenix BIOS Version 1.02 (MP version) BIOS ROM type SST/AMD 1MB CMOS Boot Block Flash Memory BIOS ROM size 1M byte FLASH ROM SST BIOS package 10-lead TSOP (10mmx20mm) Supported protocols ACPI 1.0b/2.0/3.0 compliance, PCI 2.2, System/HDD Password Security Control, INT 13H Extenstions, PnP BIOS 1.0a SMBIOS 2.4, BIOS Boot Specification, Simple Boot Flag 1.0, Boot Block, PCI Bus Power Management Interface...
Page 46
36Chapter 1 NOTE: Above table lists some system memory configurations. You may combine DIMMs with various capacities to form other combinations. On above table, the configuration of slot 1 and slot 2 could be reversed. Memory Combinations Slot 1Slot 2Total Memory 0MB 256MB 256MB 0MB 512MB 512MB 0MB 1024MB 1024MB 0MB 2048MB 2048MB 256MB 256MB 512MB 256MB 512MB 768MB 256MB 1024MB 1280MB 256MB 2048MB 2304MB 512MB 256MB 768MB 512MB 512MB 1024MB 512MB 1024MB 1536MB 512MB 2048MB 2560MB 1024MB 0MB...
Page 47
Chapter 137 Connector type USB Wireless Module 802.11b/g ItemSpecification Chipset Acer InviLink™ Nplify™ 802.11a/b/g/Draft-N Wi-Fi CERTIFIED® network connection, supporting Acer SignalUp™ wireless technology, or Acer InviLink™ 802.11b/g Wi-Fi CERTIFIED® network connection, supporting Acer SignalUp™ wireless technology Data throughput 11~54 Mbps, up to 270 Mbps for Draft-N Protocol 802.11b+g, Draft-N Interface PCI bus (mini PCI socket for wireless module) Hard Disk Drive Interface Item Vendor &...
Page 48
38Chapter 1 Voltage tolerance5V(DC) +/- 5% 5V(DC) +/- 5% 5V(DC) +/- 5% Super-Multi Drive module ItemSpecification Vendor & model name PANASONIC Super-Multi DRIVE 9.5mm Slot DL 8X UJ-875 Performance Specification With CD Diskette With DVD Diskette Transfer rate (KB/sec) Sustained: Max 3.6Mbytes/secSustained: Max 10.08Mbytes/sec Buffer Memory 2MB Interface PATA Applicable disc format Applicable disc format CD: CD-DA, CD-ROM, CD-ROM XA, PhotoCD (multi-session), Video CD, Cd-Extra (CD+), CD-text DVD:...
Page 49
Chapter 139 Audio Interface ItemSpecification Audio Controller Realtek ALC883 Azalia and Amplifier Maxim MAX9710 & MAX4411 Audio onboard or optional Built-in Mono or Stereo Stereo Resolution 18 bit stereo full duplex Compatibility HD audio Interface; S/PDIF output for PCM or AC-3 content Sampling rate 1Hz resolution VSR (Variable Sampling Rate) Internal microphone Yes Internal speaker / Quantity Yes/2 (1.5W speakers) Video Memory ItemSpecification Chipset UMA Memory size 8 MB ItemSpecification Chipset...
Page 50
40Chapter 1 Keyboard ItemSpecification Keyboard controller NS PC97541V Total number of keypads 84-/85-key Windows logo key Yes Internal & external keyboard work simultaneouslyPlug USB keyboard to the USB port directly: Yes Battery ItemSpecification Vendor & model name Panasonic 3S2P Battery Type Li-ion Pack capacity 6Cell 2.9 MAH Number of battery cell 6 Package configuration 3 cells in series, 2 series in parallel Normal voltage 11.1V Charge voltage 19.0 v LCD 12.1” inch ItemSpecification Vendor &...
