Acer Ferrari 1200 Service Guide
Here you can view all the pages of manual Acer Ferrari 1200 Service Guide. The Acer manuals for Notebook are available online for free. You can easily download all the documents as PDF.
Page 151
Chapter 6141 LOWER CASE W/MODEM&DC-IN CABLE&SPEAKER60.FRA01.001 UPPER CASE W/FINGER PRINT HOLE 60.FRA01.002 MIDDLE COVER 42.FR901.001 Speaker SPEAKER 23.FRA01.001 CPU/Processor CPU AMD TURIONX2 RM70 PGA 2.0G 1M 638 35W GRIFFIN B1KC.TRM02.70K CPU AMD TURIONX2 ZM80 PGA 2.1G 2M 638 35W GRIFFIN B1KC.TZM02.800 CPU AMD TURIONX2 ZM82 PGA 2.2G 2M 638 35W GRIFFIN B1KC.TZM02.820 CPU AMD TURIONX2 ZM84 PGA 2.3G 2M 638 35W GRIFFIN B1KC.TZM02.840 CPU AMD TURIONX2 ZM86 PGA 2.4G 2M 638 35W GRIFFIN B1KC.TZM02.860...
Page 152
142Chapter 6 ASSEMBLY SUPLER MULTI SLOT-IN MODULE 8X6M.FRA01.001 OPTICAL BRACKET SUPPORT 33.FR901.005 OPTICAL BRACKET 33.FRA01.001 DVD SUPER MULTI DRIVE 8X 9.5MM SLOT-IN PANASONIC UJ867 LF W/O BEZEL SATAKU.00807.063 HDD Module HDD HOLDER 42.FRA01.002 HDD 160GB 5400RPM SATA WD SEAGATE ST9160827AS F/W:2.ALAKH.16001.029 HDD 160GB 5400RPM SATA HGST HTS543216L9A300 F/W:C30CKH.16007.019 HDD 160GB 5400RPM SATA WD WD1600BEVT-22ZCT0 FW:11.01A11KH.16008.022 HDD 250GB 5400RPM SATA SEAGATE ST9250827AS...
Page 153
Chapter 6143 HDD 320GB 5400RPM SATA WD WD3200BEVT-22ZCT0 ML125 F/ W:01.01A01KH.32008.013 Heatsink CPU HEATSINK WITH FAN 60.FRA01.003 UPPER CASE THERMAL PIPE 60.FRA01.004 Keyboard KEYBOARD 12KB-FV1 84KS BLACK US KB.INT00.171 KEYBOARD 12KB-FV1 84KS BLACK HEBREWKB.INT00.172 KEYBOARD 12KB-FV1 85KS BLACK UK KB.INT00.173 KEYBOARD 12KB-FV1 85KS BLACK TURKISHKB.INT00.174 KEYBOARD 12KB-FV1 84KS BLACK THAILANDKB.INT00.175 KEYBOARD 12KB-FV1 85KS BLACK SWISSKB.INT00.176 KEYBOARD 12KB-FV1 85KS BLACK...
Page 154
144Chapter 6 KEYBOARD 12KB-FV1 88KS BLACK JAPANESEKB.INT00.188 KEYBOARD 12KB-FV1 85KS BLACK ITALIANKB.INT00.189 KEYBOARD 12KB-FV1 84KS BLACK ISRAELKB.INT00.190 KEYBOARD 12KB-FV1 85KS BLACK HUNGARIANKB.INT00.192 KEYBOARD 12KB-FV1 84KS BLACK GREEKKB.INT00.193 KEYBOARD 12KB-FV1 85KS BLACK GERMANKB.INT00.194 KEYBOARD 12KB-FV1 85KS BLACK FRENCHKB.INT00.195 KEYBOARD 12KB-FV1 85KS BLACK DANISHKB.INT00.198 KEYBOARD 12KB-FV1 85KS BLACK CZECHKB.INT00.199 KEYBOARD 12KB-FV1 84KS BLACK TA I WA...
Page 155
Chapter 6145 LCD/CAMERA CABLE 12.1 50.FRA01.001 CAMERA 0.3M SUYIN CN0314-SN30- OV03-157.TQ901.001 CAMERA 0.3M CHICONY CNF701721004971L57.TQ901.002 LCD COVER 1 2.1 W/LOGO&ANTENNA 60.FR901.005 LCD BEZEL 12.1 W/CAMERA HOLE & MIC 60.FRA01.005 LED LCD AUO 12.1 WXGA GLARE B121EW09 V0 LF 220NIT 16MSLK.12105.014 Mainboard MAINBOA RDMAINBOARD FERRARI_7_GT ATI RS780 LF W/RTC BATTERY & MODEM BOARD MB.FRA01.001 Memory SODIMM 1GB DDRII667 NANYA NT1GT64U8HB0BN-3C LF (0.09U)KN.1GB03.014 SODIMM 1GB DDRII667 SAMSUNG...
Page 156
146Chapter 6 SODIMM 2GB DDRII667 MICRON MT16HTF25664HY-667E1KN.2GB04.001 SODIMM 2GB DDRII667 SAMSUNG M470T5663QZ3-CE6 LFKN.2GB0B.003 SODIMM 2GB DDRII667 HYNIX HYMP125S64CP8-Y5 LFKN.2GB0G.004 MISCELLANEOUS RUBBER FOOT FRONT RIGHT FOR FERRARI747.FR901.001 RUBBER FOOT FRONT LEFT FOR FERRARI747.FR901.002 RUBBER FOOT BACK RIGHT FOR FERRARI747.FR901.003 LCD SCREW RUBBER RIGHT 47.FR901.008 LCD SCREW RUBBER LEFT 47.FR901.009 RUBBER FOOT FRONT SMALL RIGHT FOR FERRARI747.FR901.005 RUBBER FOOT FRONT SMALL...
Page 157
Chapter 6147
Page 158
Appendix A148 Ferrari 1200 Series Model Definition and Configuration Appendix A
Page 159
Appendix B149 This computer’s compatibility is tested and verified by Acer’s internal testing department. All of its system functions are tested under Windows® XP Home, Windows® XP Pro environment. Refer to the following lists for components, adapter cards, and peripherals which have passed these tests. Regarding configuration, combination and test procedures, please refer to the Ferrari 1200 series Compatibility Test Report released by the Acer Mobile System Testing Department. Test Compatible...
Page 160
150Appendix B Microsoft® Windows® Vista Environment Test ItemSpecification CRT Port Test CRT Monitor Acer 211c 21”, ViewSonic G220F, ViewSonic PF790 19” LCD Monitor Acer FP751 17” TFT LCD, Acer AL1521, Acer AL1721, ViewSonic VD201b, Westinghouse W37G, HP LP2065, HP S9500 Projector Dell 3300MP USB Port Test USB Keyboard/Mouse Microsoft Natural Keyboard Pro Dell USB Keyboard Logicool USB Mouse (OWCM-USB) Logitech USB Wheel Mouse Logitech First Wheel Mouse Dell Dell by Logitech Dell Internet Navigator...
