Sony Vegas 5 Manual

CHP. 8USING THE MIXER
149
Soloing a bus
Soloing isolates a bus’s playback so that you can focus on a specific output. You can solo more than one bus at
a time. To solo the bus, click the
Solo button ( ). Click the button again to turn off soloing.
Naming or renaming a bus
Every bus in the Mixer window has an editable name.
1.Double-click the bus name.
2.Ty p e  a  n e w  n a m e .
3.Press   to save the name.
Panning a bus
Like volume, the pan slider in the track header can function as a trim control...

150
USING THE MIXERCHP. 8
Using assignable effects chains
Assignable effects are only available in the full version of Vegas software.
Assignable effects allow you to send various levels of multiple tracks to a single audio effect chain. Like
busses, these controls reside in the Mixer window and support plug-in chains. In addition, you can route
assignable effects outputs to project busses.
Click the
Insert Assignable FX button ( ) in the
Mixer window to add an assignable effects chain to
your...

CHP. 8USING THE MIXER
151
Tip: To use the output fader to control the wet/dry mix of the
assignable effects chain, set each plug-in to 100% wet. Use
the output (effects return) fader to balance the dry track
signal with the wet plug-in signal.
You can work with assignable effects controls in much the same way you work with busses. Use the same
methods described earlier in this chapter for adjusting volume, adjusting for clipping, muting, soloing, and
renaming. For more information, see Working with...

152
USING THE MIXERCHP. 8
Routing assignable effects chains to busses
When you add assignable effects to your project, you can assign them to a specific bus for output. The bus
mixes the assignable effects chain’s plug-ins along with any tracks that may be routed to the same bus. For
more information, see Audio signal flow on page 34.
This option is only available if the project contains multiple busses. For more information, see Adding busses to
a project on page 145.
1.Click the Bus button ( ) on...

CHP. 9ADDING AUDIO EFFECTS
CHAPTER153
Adding Audio
Effects
You can use audio effects, or plug-ins, to improve the quality of the audio in a production or to create special
artistic effects. In addition to the DirectX® plug-in effects included with Vegas® software, you can also use
other Sony Pictures Digital plug-ins and third-party plug-ins.
Using audio effects
There are three ways to use audio plug-ins: track effects, bus effects, and assignable effects. You can access
these plug-ins by clicking...

154
ADDING AUDIO EFFECTSCHP. 9
Using plug-in chains
A plug-in chain is a sequence of plug-ins to be applied to
tracks, busses, or assignable effects. A plug-in chain can
contain one or more plug-ins. The same plug-in can be added
to a chain more than once.
After the plug-in chain is created, the audio is processed by
each plug-in in order. The plug-ins are cumulative so, in some cases, you may want to rearrange their order to
achieve the desired effect.
If you’re working with a 5.1 surround...

CHP. 9ADDING AUDIO EFFECTS
155
2.Click the Plug-In Chain button ( ) on the window. The Plug-In Chooser dialog appears. Plug-ins already
in the chain appear at the top of the dialog.
3.Select a plug-in and click Add.
4.Repeat step three to add as many plug-ins as you need to create the desired effect.
5.Click OK to close the Plug-in Chooser dialog. The plug-in chain appears just below the title bar in the
appropriate FX window (Audio Plug-In or Video Track FX).
Adding plug-ins via the Plug-In Manager...

156
ADDING AUDIO EFFECTSCHP. 9
3.Drag a plug-in to a track, bus, or assignable effects chain.
Tip: You can select multiple plug-ins and add them at the
same time by dragging them to the desired location.
4.Confirm that the plug-ins were added by clicking the Track FX, Bus FX or Assignable FX button () to view
the appropriate FX window (Audio Plug-In or Video Track FX). You can customize the settings for the
effects at this time.
Saving customized plug-in presets
Each plug-in has a number of presets...

CHP. 9ADDING AUDIO EFFECTS
157
3.Once the chain’s plug-ins are in the order that you want, click the Close button ( ) in the upper-right
corner to close the window.
Arranging the plug-in order from the Plug-In Chooser dialog
1.
Click the Tr a c k  F X, Bus FX or Assignable FX button ( ). The appropriate FX window (Audio Plug-In or
Video Track FX) appears.
2.Click the Plug-In Chain button ( ). The Plug-In Chooser dialog appears with the plug-in chain displayed
at the top.
3.Drag a plug-in to a new...

158
ADDING AUDIO EFFECTSCHP. 9
Removing a plug-in from the chain in the FX window
1.
Click the Tr a c k  F X, Bus FX or Assignable FX button ( ). The appropriate FX window (Audio Plug-In or
Video Track FX) appears.
2.Select the plug-in that you want to remove.
3.Click the Remove Selected Plug-In button ( ).
Removing a plug-in from the chain in the Plug-In Chooser dialog
1.
Click the Tr a c k  F X, Bus FX or Assignable FX button ( ). The appropriate FX window (Audio Plug-In or
Video Track FX) appears....
