Sony Vegas 5 Manual

CHP. 6USING AUTOMATION
CHAPTER119
Using Automation
Automation allows you to control audio and video levels, panning, and effect parameter automation over
time. You can create fades, apply stereo panning, and vary effect parameters throughout your project.
Automation is represented on the Vegas® timeline as an envelope or set of keyframes. You can create
automation by adding envelopes or keyframes to your tracks (including bus tracks), or you can record
automation parameters by adjusting controls in...

120
USING AUTOMATIONCHP. 6
Adding or removing mute automation
1.
Select a track.
2.From the Insert menu, choose Audio Envelopes or Video Envelopes, or right-click in the track list and
choose
Insert/Remove Envelope from the shortcut menu.
3.From the submenu, choose Mute. A check mark is displayed next to the command, and an envelope is
added to the timeline.
4.You can adjust the automation by editing the envelope in the timeline or by using the Mute button   in
the track header when
Show...

CHP. 6USING AUTOMATION
121
When the track has a volume envelope and the track automation mode is set to Read, the fader/slider
will follow the envelope during playback but cannot be adjusted.
When the track automation mode is set to
To u c h or Latch, the fader/slider edits the envelope setting at
the cursor position. If the track does not have a volume/pan envelope, an envelope will be added when
you adjust the fader/slider.
If multiple tracks are selected, all selected tracks are adjusted.
If...

122
USING AUTOMATIONCHP. 6
Bus automation (audio only)
You can use bus automation envelopes to vary the level of a track sent to a bus.
Adding or removing a bus automation envelope
Before you can add a bus envelope, youll need to specify the number of busses for your project.
1.Select an audio track.
2.From the Insert menu, choose Audio Envelopes, or right-click in the track list and choose Insert/Remove
Envelope
 from the shortcut menu.
3.From the submenu, choose the bus where you want to send the...

CHP. 6USING AUTOMATION
123
1.Click the Tr a c k  F X  button ( ) on a track to open the Audio Plug-In window.
If no track effects exist, clicking the
Track FX button displays the Plug-In Chooser. Use the Plug-In
Chooser to create an effect chain including an automatable plug-in.
2.Click the Configure FX Automation button ( ) to display the FX Automation Chooser.
3.Click a plug-in at the top of the FX Automation Chooser. A list of the effect’s automatable parameters
appears.
4.Select the check box for...

124
USING AUTOMATIONCHP. 6
Adjusting effect automation settings
You can adjust automated effect parameters by editing the envelopes in the timeline or by recording
automation with the controls in the Audio Plug-In Window.
If youve enabled the
Bypass parameter for a plug-in, you can click the Bypass button in the plug-ins banner
to toggle the Bypass envelope at the cursor position.
Note: When you automate an effect’s frequency parameter,
such as the frequency parameters in the track EQ effect, you...

CHP. 6USING AUTOMATION
125
Adding a motion blur envelope
Motion blur can help you make computer-generated animation look more realistic. For example, if you use
track motion or event pan/crop to move a clip across the frame, each frame is displayed clearly when no
motion blur is applied. Turning on motion blur adds a motion-dependent blur to each frame to create the
appearance of smooth motion in the same way a fast-moving subject is blurred when you take a photograph
with a slow shutter speed.
Note:...

126
USING AUTOMATIONCHP. 6
Working with track envelopes
Envelopes represent volume, audio panning, opacity, and fade to color automation settings in the timeline.
Composite Level envelopes and Fade to Color envelopes are only available in the full version of Vegas software.
Adding envelope points
Once you add an envelope to a track, you may add points to it. These points are used to edit the envelope
line in order to automate the control.
1.Place the mouse pointer on the envelope’s line.
The pointer...

CHP. 6USING AUTOMATION
127
Moving envelope points
Once you have added envelope points, you can raise and lower them to different levels along the timeline, or
you can adjust the envelope’s location along the timeline by dragging it right or left. You can move one
point at a time, even during playback and check the results in real time. If snapping is enabled, the envelope
point snaps to time divisions as you drag. Hold   while dragging to override snapping.
Tip: You can move multiple envelope points...

128
USING AUTOMATIONCHP. 6
If youve added effect automation envelopes to a track, the track can get cluttered. Click the down arrow
next to the
Track FX button   and choose an envelope from the drop-down list to select which envelope
you want to display.
Removing track envelopes
When an envelope is removed, the events on the track no longer have automated control and the envelope
line no longer displays.
1.Select the track(s) from which you want to remove envelopes.
2.From the Insert menu, choose...
