 OPERATION

Roadie 25K User’s Manual 3-65

Figure 3.38. Match Zones to Center Color Temperature
Repeat the color adjustment of sides and corners for each edge of the screen that does
not yet match the center (note that each corner is adjustable in either of its two
adjacent “side” menus). When done, all areas of a given screen should match. Repeat
Steps
2a & 2b for all remaining screens.
Step 3: Adjust Light Output in 8 Zones
3a) For each screen, compare the light output of each edge and...

 OPERATION
3-66
Roadie 25K User’s Manual
Canceling Brightness Uniformity
If you do not want to use or apply Brightness Uniformity settings, delete the
checkmark from the “Uniformity Enable” checkbox at the top of the Brightness
Uniformity menu.
Christie Edge Blending is an innovative set of software functions that can quickly and
easily blend whitelevels along the edges of multiple adjacent projected images to
create a single seamless larger image.
What is a Blend?
In simple terms, a blend...

 OPERATION

Roadie 25K User’s Manual 3-67
compensate for curves. Once downloaded to the projector, simply apply the desired
custom “user” blend by selecting it in the Blending Enable pull-down list.

Edge blending software controls are located in the 2-page Edge Blending submenu—
access via Configuration menu, then go to the Geometry and Color menu and select
Edge Blending. The More option opens the second page of the Edge Blending
submenu.
Main Functions
Use edge blending controls to set the...

 OPERATION
3-68
Roadie 25K User’s Manual

 OPERATION

Roadie 25K User’s Manual 3-69

Figure 3.43. Set Starting Points for Each Projector
4. SET BLEND WIDTH: On one projector, increase the Blend Width for an overlapping
edge (for example, if the projector’s image is on left, its right edge overlaps the
adjacent image—adjust Right Blend Width). Use the same setting on the second
projector for this shared edge.
5.  Re-adjust width (both projectors) until the overly bright band at the midpoint of
the overlapping blends disappears or just...

 OPERATION
3-70
Roadie 25K User’s Manual
enter the factory default “ccm7” login and password to open the program. If the
projector is powered up, you can access assorted menu options and slidebars.
Repeat for remaining networked projectors as desired. Keep in mind that multiple
units can be controlled from one PC, but each unit will be in its own ChristieNET
interface (web browser) at the PC. Likewise, you can make up to five separate web
locations to a single projector.
The default login...

 OPERATION

Roadie 25K User’s Manual 3-71
Turn the horizontal and/or vertical
offset knobs as necessary so that the
image is square on the screen with no
keystoning. For best results, avoid
extreme offsets characterized by corner
vignettes on a white test pattern.
For more vertical offset range, it is
possible that mechanical TILT should
be changed to help compensate for
significant differences in screen and
lens height. Refer back to Section 2.
NOTE: Refer back to Figure 2.13 and
Figure...

 OPERATION
3-72
Roadie 25K User’s Manual
Note that text-based status/error messages also appear in the LCD Status Display
window above the keypad at the rear of the projector. They are accompanied by their
corresponding 2-digit error code next to the
keypad, legible at a greater distance. Normal
operation is indicated by the “00”status code.
Invalid User Entry
A keypad entry not recognized by the projector triggers a short on-screen error
message identifying the problem. For example, if you...

 OPERATION

Roadie 25K User’s Manual 3-73
System Warnings
A system warning indicates that a system malfunction has been detected (see Status
LED Codes, below). A system warning message replaces any input signal message
and disappears when the input signal status changes. While the projector will remain
operational, the message indicates the presence of a potentially serious problem that
should be reported to the manufacturer. You can press
 Exi t to remove the
message, but for best results you...

 OPERATION
3-74
Roadie 25K User’s Manual
Table 3.6. System Error Codes
Code Description GENERAL 12  Software error. Contact dealer/factory. 13  CRC error in flash ROM. Download new software. 14  Engineering-only programming is complete. Call Christie, replace TIPM. 15  Attempting to download s/w code without being in boot mode 16  Invalid interrupt. Power off/on. If persists, contact dealer/factory. 17  User has forced system to stay in boot mode 18  Attempting to program boot mode without jumper...
