Panasonic Video Multiplexer Wj Fs216 Operating Instructions

-8-
MULTISCR:
Select this mode to monitor the camera pictures.
In MULTISCR mode you can perform the following
monitoring operations:
1. Camera picture
• Single spot picture
• Multi spot picture
• Single spot picture sequence
• Quad picture sequence
• Still multi spot picture
• Multi spot picture zoom
The menu content is different depending on the
selected mode.  (Compare MENU 1 OF 3 for MUL-
TIPLEX and MULTISCR mode below.) This is
described in more detail on the following pages.
    * MENU 1 OF 3 *...

-9-
2. ALARM BUZZER
The buzzer beeps when this unit receives the alarm
signal.  You can adjust the buzzer time between 1
and 60 seconds by changing the ALARM BUZZER
parameter.
1. Move the cursor to the ALARM BUZZER parameter.
2. Select the buzzer time.
OFF:The alarm buzzer does not beep when the
alarm signal is received.
1-30, 60S:The buzzer keeps on beeping for the
duration you set.  The letter “S” stands for sec-
onds.
The factory setting is 2S.
    * MENU 1 OF 3 *
 DYNAMIC REC     OFF
 ALARM BUZZER...

-10-
1. Move the cursor to SETUP in TITLE SETUP.
B. Setting up MENU 2 OF 3 in
MULTIPLEX mode
The context of MENU 2 OF 3 will not change if the
SYSTEM MODE parameter in MENU 3 OF 3 is
changed.
An example is shown below.
1. TITLE SETUP
A title consisting of up to 8 alphanumeric characters
can be displayed on the monitor.
    * MENU 2 OF 3 *
 TITLE SETUP *
 TITLE POSITION *
 TITLE DISPLAY     ON
 STILL/ALARM DISP  ON
    * MENU 2 OF 3 *
 TITLE SETUP *
 TITLE POSITION *
 TITLE DISPLAY     ON
 STILL/ALARM...

-11-
3. TITLE DISPLAY
This parameter lets you decide whether or not to
have the title displayed.
1. Move the cursor to the TITLE DISPLAY parameter.
    * MENU 2 OF 3 *
 TITLE SETUP *
 TITLE POSITION *
 TITLE DISPLAY     ON
 STILL/ALARM DISP  ON
2. Select ON or OFF.
ON:Title display
OFF:No title display
The factory setting is ON.
4. STILL/ALARM DISP
This parameter lets you decide whether or not to
have the word “STILL” displayed when a picture is
paused by pressing button 16 (STILL ON), or the
word...

-12-
2. Press button 15 (SET). The SEQUENCE menu
appears on the monitor.
3. Move the cursor to the sequence number by press-
ing buttons 9-12 (D
D, C
C, A
A, B
B).
4. Select the channel by pressing button 13 (-) or 14
(+).
5. Move the cursor to the dwell time by pressing but-
ton 12 (B
B).
6. Select the desired dwell time by pressing button 13
(-) or 14 (+).
If you select OFF for the dwell time, the selected
channel is automatically skipped.
7. Repeat steps 3 to 6 to determine the sequential
order and...

-13-
    * MENU 1 OF 3 *
 AUTO RESET      60S
 ALARM BUZZER     2S
 ALARM OUTPUT     2S
 MULTISCR CH SET *
    * MENU 1 OF 3 *
 AUTO RESET      60S
 ALARM BUZZER     2S
 ALARM OUTPUT     2S
 MULTISCR CH SET *
      ** CH SET **
 1 1CH        9   9CH
 2 2CH       10  10CH
 3 3CH       11  11CH
 4 4CH       12  12CH
 5 5CH       13  13CH
 6 6CH       14  14CH
 7 7CH       15  15CH
 8 8CH       16  16CH
      ** CH SET **
 1 1CH         9   9CH
 2 2CH
 3 3CH
 4 4CH
 5 5CH
 6...

-14-
B. Setting up MENU 2 OF 3 in
MULTISCREEN mode
MENU 2 OF 3 in the MULTISCR mode is the same
as in the MULTIPLEX mode. See page 10 for the
settings and procedures of the MENU 2 OF 3.
C. Setting up MENU 3 OF 3 in
MULTISCREEN mode
1. BORDER
This item is the same as in MENU 3 OF 3 in the
MULTIPLEX mode. See page 11 for the settings
and procedures.
2. AUTO SKIP
This item is the same as in MENU 3 OF 3 in the
MULTIPLEX mode. See page 11 for the settings
and procedures.
3. SEQUENCE SETUP
This item is the...

A. Single Spot Picture
1. Set the MODE SELECT/CAMERA SELECT switch to
CAMERA SELECT.
2. Press one of the camera selection buttons for dis-
play on the monitor.
The LED on the selected button lights and the
selected camera picture appears on the monitor.
B. Single Spot Picture Sequences
1. Set the MODE SELECT / CAMERA SELECT switch
to CAMERA SELECT.
2. Press the SEQUENCE / ALARM RESET button.
A sequence of single pictures is displayed in the
order and dwell time selected for the SEQUENCE
SETUP parameter...

nRecording on the Time Lapse VTR
Confirm the REC MODE parameter. See page 9 for
details.
Note:When T/L is selected but no camera switching
signal is supplied, time lapse recording will not
work properly.  In this case, supply the camera
switching signal or set REC MODE to 4-255 FIELDS
for normal recording.
nMonitoring the Playback Picture
Caution:
Set the time lapse VTR to the playback mode.
Recorded tapes should be played back in NOR-
MAL or TIME LAPSE for the time mode.
Notes:
• This unit does not...

-17-
B. Multi Spot Picture
First select a display pattern.
1. Operate the VTR in playback mode.
2. Set the MODE SELECT/CAMERA SELECT switch to
MODE SELECT.
3. Press button 8 (CAMERA/VTR).
The CAMERA/VTR indicator lights.
4. Set the MODE SELECT/CAMERA SELECT switch to
CAMERA SELECT.
5. Press the ZOOM/MULTISCREEN/QUAD SHIFT but-
ton. The multi spot playback picture appears on the
monitor screen.
6. Set the MODE SELECT/CAMERA SELECT switch to
MODE SELECT.
7. Press button 1 ( ), 2 ( ), or 3 ( ) to select...
