Acer Travelmate 630 Service Guide

Chapter 481
Touchpad Check
If the touchpad doesn’t work, do the following actions one at a time to correct the problem. Do not replace a
non-defective FRU:
1.
Reconnect the touchpad cables.
2.
Replace the touchpad.
3.
Replace the main board.
After you use the touchpad, the pointer drifts on the screen for a short time. This self-acting pointer movement
can occur when a slight, steady pressure is applied to the touchpad pointer. This symptom is not a hardware
problem. No service actions are necessary...

82Chapter 4
Power-On Self-Test (POST) Error Message
The POST error message index lists the error message and their possible causes. The most likely cause is
listed first.
NOTE:
 Perform the FRU replacement or actions in the sequence shown in FRU/Action column, if the FRU
replacement does not solve the problem, put the original part back in the computer. Do not replace a
non-defective FRU.
This index can also help you determine the next possible FRU to be replaced when servicing a computer.
If the...

Chapter 483
Previous boot incomplete - Default
configuration usedRun “Load Default Settings” in BIOS Setup Utility.
RTC battery
Main Board
Memory size found by POST differed from
CMOSRun “Load Default Settings” in BIOS Setup Utility.
DIMM
Main Board
Diskette drive A error Check the drive is defined with the proper diskette type in BIOS
Setup Utility
See “External Diskette Drive Check” on page 78.
Incorrect Drive A type - run SETUP Check the drive is defined with the proper diskette type in BIOS...

84Chapter 4
Index of Symptom-to-FRU Error Message
Error Message List
No beep Error MessagesFRU/Action in Sequence
No beep, power-on indicator turns off and LCD
is blank.Power source (battery pack and power adapter). See “Power
System Check” on page 79.
Ensure every connector is connected tightly and correctly.
Reconnect the DIMM.
LED board.
Main Board.
No beep, power-on indicator turns on and LCD
is blank.Power source (battery pack and power adapter). See “Power
System Check” on page 79.
Reconnect...

Chapter 485
Indicator-Related Symptoms
Symptom / ErrorAction in Sequence
Indicator incorrectly remains off or on, but
system runs correctlyReconnect the inverter board
Inverter board
Main Board
Power-Related Symptoms
Symptom / ErrorAction in Sequence
Power shuts down during operation Power source (battery pack and power adapter). See “Power
System Check” on page 79.
Battery pack
Power adapter
Hard drive & battery connection board
Main Board
The system doesn’t power-on. Power source (battery pack and...

86Chapter 4
Power Management-Related Symptoms
Symptom / ErrorAction in Sequence
The system will not enter hibernation Keyboard (if control is from the keyboard)
Hard disk drive
Main Board
The system doesnt enter hibernation mode
and four short beeps every minute.See “Hibernation Mode” on page 28.
Press Fn+F4 and see if the computer enters hibernation mode.
Touchpad
Keyboard
Hard disk connection board
Hard disk drive
Main Board
The system doesn’t enter standby mode after
closing the LCDSee “Standby...

Chapter 487
NOTE: If you cannot find a symptom or an error in this list and the problem remains, see “Undetermined
Problems” on page 88.
Serial or parallel port device problems. Ensure the “Serial Port” in the Devices Configuration” of BIOS
Setup Utility is set to Enabled.
Device driver
Device cable
Device
Main Board
Keyboard/Touchpad-Related Symptoms
Symptom / ErrorAction in Sequence
Keyboard (one or more keys) does not work. Reconnect the keyboard cable.
Keyboard
Main Board
Touchpad does not work....

88Chapter 4
Intermittent Problems
Intermittent system hang problems can be caused by a variety of reasons that have nothing to do with a
hardware defect, such as: cosmic radiation, electrostatic discharge, or software errors. FRU replacement
should be considered only when a recurring problem exists.
When analyzing an intermittent problem, do the following:
1.
Run the advanced diagnostic test for the main board in loop mode at least 10 times.
2.
If no error is detected, do not replace any FRU.
3.
If any...

Chapter 489
Index of PQA Diagnostic Error Code, Message
Error CodeMessageAction in Sequence
16XXX Backup battery error Backup battery
01XXX CPU or main board error Reload BIOS default setting.
Main Board
02XXX Memory error DIMM
Main Board
03XXX Keyboard error Reset Keyboard
Keyboard
Main Board
04XXX Video error Main Board
05XXX Parallel Port error Main Board
06XXX Serial port or main board error Main Board
07XXX Diskette drive error Diskette drive
Main Board
08XXX Hard disk error Reload BIOS default...
