Steinberg Cubase Essential 4 Operation Manual

9
Using markers

82
Using markers
About markers
Markers are used to locate certain positions quickly. If you
often find yourself jumping to a specific position within a
project, you should insert a marker at this position. There
are two types of markers:
 Cycle markers allow you to store the start and end positions of
a range.
 Standard markers store a specific position.
Markers can be created and edited in several ways:
 By using the Marker window (see below).
 By using the Marker track (see “Using the Marker...

83
Using markers
Moving marker positions in the Marker window
The Move button in the Marker window can be used to
“reprogram” marker positions. Proceed as follows:
1.Set the project cursor to the position to which you
want to move (or re-program) a marker.
2.Select the marker that you want to change in the
Marker window.
Do not select the marker by clicking in the leftmost column, as this will
move the project cursor to this marker.
If a cycle marker is selected, the Move operation affects
the cycle...

84
Using markers
Editing markers on the Marker track
The following editing functions can be performed directly
on the Marker track:
Adding position markers “on the fly”.
Use the [Insert] key (Win) or the “Add Marker” button in the Track list for
the Marker track to add position markers at the current cursor position
during playback.
Adding a cycle marker at the left and right locator
positions.
Clicking the “Add Cycle Marker” button in the Track list for the Marker
track adds a cycle marker...

85
Using markers
Using markers to make range selections in the
Project window
Besides enabling you to quickly move the project cursor
and the locators, markers can be used in conjunction with
the Range Selection tool to make range selections in the
Project window. This is useful if you quickly want to make
a selection that spans all tracks in the project.
Double-click with the Range Selection tool between any
two markers – this creates a selection range between the
markers, spanning all tracks in...

10
The mixer

87
The mixer
About this chapter
This chapter contains detailed information about the ele-
ments used when mixing audio and MIDI, and the various
ways you can configure the mixer.
Some mixer-related features are not described in this
chapter. These are the following:
Setting up and using audio effects.
See the chapter “Audio effects” on page 103.
Setting up and using MIDI effects.
See the chapter “MIDI realtime parameters and effects” on page 205.
Automation of all mixer parameters.
See the chapter...

88
The mixer
Configuring the mixer
The mixer window can be configured in various ways to
suit your needs and to save screen space. Here follows a
run through of the various view options (the following de-
scriptions assume that you have an active project contain-
ing some tracks):
The mixer shows the channel faders for the various tracks
of your project. On the right of the fader panel you find the
output channel fader. On the left is the common panel
which allows for global settings affecting all...

89
The mixer
Showing/hiding individual channels (the “Can
Hide” setting)
You can also show/hide individual channels of any type in
the mixer. For this, you can assign channels a “Can Hide”
status, which allows you to hide these channels collec-
tively. Proceed as follows:
1.Pull down the View options pop-up menu for the chan-
nel you want to hide and activate the “Can Hide” option or
[Alt]/[Option]-click the / icon (visible when moving the
mouse pointer to the top middle of a channel strip) for the...

90
The mixer
About the Command Target
Command targets let you specify which channels should
be affected by the “commands” (basically all the functions
that can be assigned key commands) when working with
the Mixer, e.g. the width setting of the channel strips, etc.
You can set command targets using the Mixer common
panel or the context menu.
The following options are available:
All Channels
Select this if you want your commands to affect all channels.
Selected Only
Select this if you want your...
