Page 241
C0377CONNECTOR DETAILS DEFENDER 02MY C037 7 Description:Main harness to chassis harness Location:Rear of engine compartment Colour:ORANGE Gender:Female P5562 C0378 C0391C0377 C0392 C0376C0390 CavColCct 1SBALL 2WBALL 3WGALL 4BGALL 5GBALL 6OGALL
Page 242
CONNECTOR DETAILSC0378 DEFENDER 02MY C0 378 Description:Main harness to chassis harness Location:Rear of engine compartment Colour:ORANGE Gender:Male P5562 C0378 C0391C0377 C0392 C0376C0390 CavColCct 1PALL 4WP4
Page 243
C0381CONNECTOR DETAILS DEFENDER 02MY C038 1 Description:Heater element - Rear screen Location:LH side of taildoor Colour:BLACK Gender:Female P6673 C0381 C0832 CavColCct 1WB1
Page 244
CONNECTOR DETAILSC0382 DEFENDER 02MY C0 382 Description:Heater element - Rear screen Location:RH side of tail door Colour:BLACK Gender:Female P6672 C0833 C0382 CavColCct 1B1
Page 245
C0388CONNECTOR DETAILS DEFENDER 02MY C038 8 Description:Motor - Wiper - Rear screen Location:Centre of taildoor, behind trim panel Colour:BLACK Gender:Female P6675 C1105 C0388 CavColCct 1B1 2RLG1
Page 246
CONNECTOR DETAILSC0390 DEFENDER 02MY C0 390 Description:Chassis harness to main harness Location:Rear of engine compartment Colour:ORANGE Gender:Male P5562 C0378 C0391C0377 C0392 C0376C0390 CavColCct 1RO10 2RB10 3RY10 4GR10 5GW10 6GP10 7S10 8W10 9GN10
Page 247
C0391CONNECTOR DETAILS DEFENDER 02MY C039 1 Description:Chassis harness to main harness Location:Rear of engine compartment Colour:ORANGE Gender:Male P5562 C0378 C0391C0377 C0392 C0376C0390 CavColCct 1SBALL 2WB10 3WGALL 4BG10 5GBALL 6OG11
Page 248
CONNECTOR DETAILSC0392 DEFENDER 02MY C0 392 Description:Chassis harness to main harness Location:Rear of engine compartment Colour:ORANGE Gender:Female P5562 C0378 C0391C0377 C0392 C0376C0390 CavColCct 1P10 4WP11
Page 249
C0425CONNECTOR DETAILS DEFENDER 02MY C042 5 Description:Resistor - Blower motor Location:Behind RH side of fascia Colour:WHITE Gender:Female NO PHOTO LOCATION NO CONNECTOR FACE CavColCct 1NYALL 2UALL 4GALL
Page 250
CONNECTOR DETAILSC0434 DEFENDER 02MY C0 434 Description:Earth - ABS modulator Location:Top of bulkhead - centre Colour:TIN-PLATE Gender:Female P6727 C0123 C0434C0550 CavColCct 1BALL
