Brinkmann Brinkman Qbeam Max Million Ii 2,000,000 Candlepower Spotlight Owners Manual

SPOTLIGHT OWNER’S MANUAL &
OPERATING INSTRUCTIONS
WARNING
READ AND FOLLOW ALL WARNINGS
AND INSTRUCTIONS IN THIS
MANUAL TO AVOID PERSONAL
INJURY OR PROPERTY DAMAGE.
®
800-2550-0_INSTR-MAXMILL2  7/10/02  11:49 AM  Page 1

1
• Never place spotlight face down when light is on or is still hot from recent use. Doing so could burn/ignite surfaces such
as seats, carpeting, etc. and cause major property damage. Always turn spotlight off and unplug from power source when
not in use.
• To prevent serious damage to eyesight, never look into spotlight when light is on. Do not shine light into the face of
someone else.
• Do not touch lens of spotlight when light is on or if it was recently on. The lens will be hot and could cause...

OPERATING INSTRUCTIONS
READ AND FOLLOW ALL SAFETY WARNINGS AND INSTRUCTIONS IN THE OWNER’S MANUAL
BEFORE OPERATING SPOTLIGHT.
Step 1:To activate spotlight, plug the cigarette lighter adapter into a
cigarette lighter receptacle. Move switch to ON.
WARNING:Never place spotlight face down when light is on or is
still hot from recent use. Doing so could burn/ignite
surfaces such as seats, carpeting, etc. and cause major
property damage. Always turn spotlight off and unplug
from power source when not in...

Step 5:Disconnect bulb wire from connector by holding the connector
firmly with fingers then pulling bulb wire straight out as shown
in Figure 2.
Step 6:Spread the wire retainer apart and lift up as illustrated in
Figure 3.
Step 7:Pull bulb straight out from the reflector mounting plate.
Step 8:To install new bulb, grasp the bulb from the metal end (DO NOT
TOUCH THE GLASS PART) and insert into the reflector
mounting plate. Align the slots in the bulb base with those in
the reflector mounting plate....

4
Q-BEAM ACCESSORIES
Pigtail AdaptersPigtail adapter with battery terminal clips
allow Q-Beam spotlights with cigarette lighter
plug to operate directly from a 12-volt battery.
Model 802-1704-0 (2-Ft. Cord)
Model 802-1705-0 (10-Ft. Cord)
Rechargeable Battery Pack
With Carrying Case
12-volt rechargeable battery pack adds total
mobility to your Q-Beam. Includes cigarette
lighter receptacle, 120-volt charging
transformer and a heavy-duty, woven nylon
carrying case with shoulder strap.
Model 802-1724-1...

For 1-year from date of purchase, The Brinkmann Corporation warrants the Q-Beam Max Million IISpotlight against defects due
to workmanship or materials to the original purchaser. The Brinkmann Corporation’s obligations under this warranty are limited
to the following guidelines:
• This warranty does not extend to the bulb.
• This warranty does not cover spot lights that have been altered or damaged due to: normal wear, abuse, improper
maintenance, improper use, disassembly of parts and/or attempted...
